MultiCam 3000 Series CNC Router

$35,000 – $80,000 depending on bed size and options Updated 2026-03-17

Key Specifications

Table Size

4x8 ft to 5x12 ft (1220x2440 mm to 1524x3658 mm)

X/Y/Z Travel

96 x 60 x 8 in (2438 x 1524 x 203 mm) standard

Spindle Power

7.5 – 18 kW (options)

Spindle Speed

Up to 24,000 RPM

Drive System

Precision rack and pinion

Rapid Traverse

Up to 2000 in/min (50 m/min)

Overview

The MultiCam 3000 Series is a high-performance production CNC router designed for sign-making, cabinet shops, aerospace composites, and industrial fabrication. Built on a heavy-duty welded steel gantry with precision rack-and-pinion drive, the 3000 Series delivers consistent cutting accuracy across large format sheets. The machine accommodates 4x8 to 5x12 foot material beds and supports multi-zone vacuum hold-down for secure workpiece clamping without fixtures. With optional automatic tool change (ATC) spindles up to 18 kW and a 24-position tool carousel, operators can program multi-step routines and run lights-out production. The 3000 Series is compatible with MultiCam's EZ Control system, offering conversational programming alongside full G-code support. Popular in North American sign and cabinet shops, the platform is backed by MultiCam's national service network.

Full Specifications

Parameter	Value
Table Size	4x8 ft to 5x12 ft (1220x2440 mm to 1524x3658 mm)
X/Y/Z Travel	96 x 60 x 8 in (2438 x 1524 x 203 mm) standard
Spindle Power	7.5 – 18 kW (options)
Spindle Speed	Up to 24,000 RPM
Drive System	Precision rack and pinion
Rapid Traverse	Up to 2000 in/min (50 m/min)
Tool Change	24-position ATC (optional)
Vacuum Hold-Down	Multi-zone vacuum table
Control	MultiCam EZ Control (PC-based)
Frame	Heavy-duty welded steel gantry

Strengths & Limitations

Strengths

Nationwide MultiCam service and support network in North America
EZ Control is beginner-friendly with conversational programming
Modular design — bed size, spindle, and ATC can be customized
Heavy gantry reduces vibration for consistent cut quality
Multi-zone vacuum table handles sheets without mechanical clamps

Limitations

Rack-and-pinion drive less precise than linear motor alternatives
EZ Control lacks advanced CAM toolpath features of dedicated software
ATC carousel limited to 24 tools vs larger carousels on machining centers
Not ideal for very thick composites requiring deep Z travel

Best For

Sign fabrication shops needing 4x8 and 5x10 sheet capacity Cabinet and furniture manufacturers running nested-based production Aerospace composite shops cutting flat panels and skins Plastics fabricators routing acrylic, HDPE, and PVC sheets

Frequently Asked Questions

01 What materials can the MultiCam 3000 Series cut?

The 3000 Series cuts wood, MDF, plywood, composites (fiberglass, carbon fiber), plastics (acrylic, HDPE, ABS), aluminum sheet up to 1/2 inch, foam, and sign blanks. It is not designed for steel cutting.

02 Does it support nested-based manufacturing software?

Yes. The EZ Control accepts G-code from any CAM package including Cabinet Vision, Microvellum, and Alphacam, all of which support nested-based production workflows.

03 How many tools does the ATC hold?

The standard ATC carousel holds 24 tools. Custom configurations with larger carousels are available for shops running complex multi-step programs.
