Takamaz XW-200

$260,000 - $380,000 Updated 2026-03-19

Key Specifications

Max Spindle

Max. 2,800

Rapid Traverse

X:30 Y:80 Z:100

Spindle Power

18.5/15 kW (25/20 HP) each spindle

Max Turn Length

150 mm (5.91 in) per spindle

max turning diameter

200 mm (7.87 in)

spindle speed

2,800 RPM (both spindles)

Overview

The Takamaz XW-200 is a twin-spindle CNC lathe stepping up to a 10-inch chuck class for production machining of medium-sized parts up to 200 mm in diameter. As the larger sibling of the 8-inch XW-130, the XW-200 extends Takamaz's twin-spindle automation philosophy to parts that simply cannot fit in the smaller platform, including larger automotive components, pump housings, gear blanks, and medium-sized hydraulic valve bodies.

Both spindles deliver substantial 18.5/15 kW of power at up to 2,800 RPM through 120 mm spindle bores, providing the torque needed for aggressive roughing on steel, cast iron, and stainless steel at the larger diameters this machine handles. The dual 10-inch collet chucks securely grip larger workpieces for heavy cutting without chatter. Each spindle has its own 8-station turret with 170 mm X-travel and 220 mm Z-travel.

The twin-spindle architecture with automatic part transfer enables complete both-end machining without operator intervention. Parts are loaded, machined on the first spindle, automatically transferred to the second spindle for back-end operations, and unloaded as finished components. This eliminates the second-operation lathe and the work-in-process inventory that manual part handling generates.

Rapid traverse rates of 24 m/min on both X and Z keep non-cutting time to a minimum. The Fanuc 0i-TF control manages multi-channel programming for synchronized or independent spindle-turret operation. The footprint of 1,990 x 2,330 mm (2,350 x 2,330 mm with loader) is compact for a twin-spindle 10-inch machine. Takamaz reports a 180% increase in cutting capacity over previous-generation models, with loader capacity for workpieces up to 8.0 kg.

Full Specifications

Parameter	Value
Max Turning Diameter	200 mm (7.87 in)
Max Turning Length	150 mm (5.91 in) per spindle
Spindle Speed	2,800 RPM (both spindles)
Spindle Motor Power	18.5/15 kW (25/20 HP) each spindle
Spindle Bore	120 mm (4.72 in)
Chuck Size	Collet, 10×2
Turret Stations	8 per turret (16 total)
X Axis Travel	170 mm (6.7 in) per turret
Z Axis Travel	220 mm (8.7 in) per turret
Rapid Traverse X	24 m/min (945 IPM)
Rapid Traverse Z	24 m/min (945 IPM)
Gantry Loader	Integrated (standard), max 8.0 kg
CNC Control	Fanuc 0i-TF
Floor Space Required	1,990 x 2,330 mm (78.3 x 91.7 in) (2,350 x 2,330 mm with loader)
Item	Ability
Spindle	Spindle bearing I.D.
Max Spindle Speed	Max. 2,800
Tool Post	Type
Maxstroke	X:170Z:220
Rapid Traverse Rate	X:30 Y:80 Z:100
Speendle Motor	AC18.5 / 15 ×2
W L	1,990 (2,350 ※) × 2,330
Cnc Control	TAKAMAZ & FANUC 0i-TF
Itemloader Specifications	Ability
Workpiece Diameter	φ200
Workpiece Length	120
Max Load Capacity	8.0

Specifications sourced from takamaz.co.jp — verified 2026-03-28

Strengths & Limitations

Strengths

10-inch chuck class with 18.5/15 kW spindles handles medium-sized parts that the 8-inch XW-130 cannot accommodate
Twin-spindle design delivers complete both-end machining in a single automated cycle
180% increase in cutting capacity over previous generation delivers significantly faster material removal
24 m/min rapid traverse on all axes minimizes non-cutting time between operations
120 mm spindle bores accommodate larger bar stock for continuous automated production
Integrated gantry loader with 8 kg capacity handles heavier medium-sized workpieces

Limitations

2,800 RPM maximum spindle speed limits surface speed on smaller-diameter features and aluminum work
8-station turrets without live tooling restrict the machine to pure turning operations
Higher cost than the 8-inch XW-130 requires larger part volumes or higher-value parts to justify
Limited Takamaz dealer and service network outside Japan and select Asian markets

Best For

High-volume production of medium-sized parts requiring both-end machining up to 200 mm diameter Automotive manufacturing of pump housings, gear blanks, brake components, and differential parts Hydraulic industry production of larger valve bodies and cylinder components with both-end features Shops upgrading from 8-inch twin-spindle machines to handle larger part diameters with the same automation Production of cast iron and steel components where 18.5/15 kW spindle power enables aggressive roughing

Frequently Asked Questions

01 What does a Takamaz XW-200 cost?

New Takamaz XW-200 machines typically price between $260,000 and $380,000 depending on tooling and loader configuration. The 10-inch platform commands a premium over the 8-inch XW-130 but handles significantly larger parts.

02 How does the XW-200 compare to the XW-130?

The XW-200 steps up to 10-inch chucks with 18.5/15 kW spindles (vs 8-inch and 15 kW), 120 mm spindle bores (vs 100 mm), and 200 mm turning diameter capability. The trade-off is lower spindle speed at 2,800 RPM vs 4,500 RPM on the XW-130.

03 Can the XW-200 handle stainless steel and tough alloys?

Yes. The 18.5/15 kW spindle power on each side provides ample torque for production turning of stainless steel, alloy steel, and cast iron at the larger diameters. The rigid 10-inch chuck provides secure clamping for heavy cuts.

04 What is the loader capacity of the XW-200?

The integrated gantry loader handles workpieces up to 8.0 kg. This accommodates most medium-sized steel and cast iron parts within the 200 mm diameter range. Parts exceeding 8 kg can be loaded manually.
