Takamaz XTL-8
Key Specifications
Max Spindle
Rapid Traverse
Spindle Power
Max Turn Length
max turning diameter
spindle speed
Overview
The Takamaz XTL-8 is a long-bed variant of Takamaz's proven XT series, extending Z-axis travel to 600 mm for production turning of longer workpieces that exceed the capability of the standard XT-8. The 8-inch chuck platform with a maximum spindle speed of 4,000 RPM (5,000 or 3,000 RPM optional) gives the machine enough envelope and speed to handle a wide variety of shaft-type components, automotive driveline parts, and hydraulic cylinders that demand both length and precision.
The spindle delivers 15/11 kW of power through a bearing bore of 100 mm (120 mm optional), providing balanced rigidity and speed for production-rate material removal on steel, cast iron, and aluminum. The extended 600 mm turning length is the XTL-8's defining specification — nearly three times the Z-travel of the standard XT-8 — opening up applications in motor shafts, toolholders, and coupling bodies that require significant longitudinal machining.
Takamaz equips the XTL-8 with an 8-station turret as standard, with a 12-station upgrade available for shops needing additional tool positions. The X-axis stroke of 190 mm covers facing, profiling, and grooving operations across the full turning diameter. Rapid traverse rates of 18 m/min on X and 24 m/min on Z keep non-cutting time to a minimum, which is critical on longer parts where tool approach distances are significant.
The integrated gantry loader handles workpieces up to 75 mm diameter and 450 mm length at loads up to 5 kg, making the XTL-8 a genuine lights-out production platform for long turned parts. The compact 1,840 x 1,860 mm footprint is remarkable for a machine with 600 mm of Z-travel, reflecting Takamaz's engineering focus on production density. The Fanuc 0i-TF Plus control provides reliable, well-supported CNC operation with Takamaz's proprietary conversational programming overlay for rapid setup of part families.
Full Specifications
| Parameter | Value |
|---|---|
| Max Turning Diameter | 200 mm (7.87 in) |
| Max Turning Length | 600 mm (23.6 in) |
| Spindle Speed | 4,000 RPM (5,000 / 3,000 optional) |
| Spindle Motor Power | AC15/11:φ100 4,000min -1(AC15/11:φ100 5,000min -1 Opt.)(AC15/11:φ120 3,000min -1 Opt.) |
| Spindle Bore | 100 mm (120 mm optional) |
| Chuck Size | Collet, 8 (10 Opt.) |
| Turret Stations | 8 (12 optional) |
| X Axis Travel | 190 mm (7.5 in) |
| Z Axis Travel | 600 mm (23.6 in) |
| Rapid Traverse X | 18 m/min (709 IPM) |
| Rapid Traverse Z | 24 m/min (945 IPM) |
| Gantry Loader | Integrated (standard), max dia 75 x 450 mm, 5 kg |
| CNC Control | Fanuc 0i-TF Plus |
| Floor Space Required | 1,840 x 1,860 mm (72.4 x 73.2 in) |
| Item | Ability |
| 8 Station Turret | 12-station turret(Option) |
| Spindle | Spindle bearing I.D. |
| Max Spindle Speed | Max.4,000 (5,000・3,000 Opt.) |
| Tool Post | Type |
| Maxstroke | X:190Z:600 |
| Rapid Traverse Rate | Y:160 Z:160 |
| W L | 1,840 × 1,860 |
| Cnc Control | TAKAMAZ & FANUC 0i-TF Plus |
| Itemloader Specifications | Ability |
| Workpiece Diameter | φ75 |
| Workpiece Length | 450 |
| Max Load Capacity | 5 |
Specifications sourced from takamaz.co.jp — verified 2026-03-28
Strengths & Limitations
Strengths
- 600 mm Z-axis travel handles shaft-type and long workpieces far beyond the capability of the standard XT-8
- 15/11 kW spindle provides serious cutting power for aggressive roughing on steel and cast iron
- Integrated gantry loader as standard enables lights-out production of long turned parts
- Compact 1,840 x 1,860 mm footprint is remarkably small for a machine with 600 mm turning length
- Fanuc 0i-TF Plus with Takamaz conversational overlay simplifies programming for families of shaft components
- Optional 12-station turret and 120 mm spindle bore expand the machine versatility for complex parts
Limitations
- Gantry loader limited to 75 mm diameter and 5 kg restricts automated operation to lighter smaller-diameter shafts
- 8-station standard turret may require frequent tool changes on complex parts with many features
- Limited Takamaz service network outside Japan compared to Mazak, Okuma, or DMG Mori
- No live tooling on standard configuration requires secondary operations for cross-drilling and milling
Best For
Frequently Asked Questions
01
New Takamaz XTL-8 machines typically price between $110,000 and $170,000 depending on spindle bore, turret configuration, and loader options. The long-bed design commands a premium over the standard XT-8 but remains competitive against comparable long-bed lathes from larger OEMs.
02
The XTL-8 extends Z-axis travel to 600 mm versus 400 mm on the XT-8, and upgrades to a 15/11 kW spindle versus 11/7.5 kW. The XTL-8 also features a standard 4,000 RPM spindle speed. These changes enable machining of longer and more demanding workpieces while maintaining the same automation philosophy.
03
The machine can finish-turn hardened steel up to approximately 55 HRC with CBN tooling, but it is primarily designed for green machining at production rates. For dedicated hard-turning applications, purpose-built machines offer better rigidity and thermal stability.
04
The integrated gantry loader handles workpieces up to 75 mm diameter, 450 mm length, and 5 kg weight. For parts exceeding these dimensions, manual loading is possible but sacrifices the machine automated throughput advantage.
