Mazak SYNCREX 32/9X

$300,000 - $440,000 Updated 2026-03-19

Key Specifications

Tool Capacity

max bar capacity

32 mm (1.260 in)

main spindle speed

7,000 RPM

main spindle power

7.5 kW (10 hp)

sub spindle speed

7,000 RPM

sub spindle power

5.5 kW (7.5 hp)

Overview

The Mazak SYNCREX 32/9X is the flagship of the 32 mm SYNCREX range, combining 32 mm (1.260 in) bar capacity with 9 axes of control and true 5-axis contouring capability. The X designation signifies the B-axis milling spindle that enables simultaneous 5-axis interpolation, bridging the gap between Swiss-type precision turning and multi-tasking machining for complex larger parts. This machine sits between the 25/9X and 38/9X, offering the 5-axis Swiss capability at a bar size that accommodates larger medical implants, hydraulic manifolds, and aerospace fittings.

The main spindle delivers 7.5 kW (10 hp) at 7,000 RPM through a collet system accepting bar stock up to 32 mm diameter. The sub-spindle provides 5.5 kW (7.5 hp) at 7,000 RPM for back-working operations and part pickup. The powerful spindle package handles aggressive cutting in stainless steel, titanium, and Inconel at 32 mm diameters. The guide bushing is removable for non-guide-bushing mode.

What distinguishes the 32/9X is its 5-axis contouring capability through the B-axis milling spindle. This enables true simultaneous 5-axis interpolation for complex contoured surfaces, undercuts, and compound-angle features that conventional Swiss machines cannot produce. The 32 mm bar capacity combined with 5-axis capability opens up complex orthopedic implants, aerospace fittings, and hydraulic manifold work. Typical configurations include 25-30 tool positions.

The MAZATROL SmoothG CNC control supports both conversational programming for standard Swiss operations and full 5-axis G-code for complex contoured features. The machine weighs approximately 4,000 kg (8,818 lb) with a footprint of roughly 3.1 x 1.6 meters. Competitors include the Citizen M32-VIII, Star SB-20R Type G, and Tornos SwissDECO 36. New machines price between $300,000 and $440,000.

Full Specifications

Parameter	Value
Max Bar Capacity	32 mm (1.260 in)
Main Spindle Speed	7,000 RPM
Main Spindle Power	7.5 kW (10 hp)
Sub Spindle Speed	7,000 RPM
Sub Spindle Power	5.5 kW (7.5 hp)
Number Of Axes	9 axes
Five Axis Contouring	Yes (B-axis milling)
Guide Bushing	Yes (removable)
Tool Stations	25-30 positions (fixed and rotary)
Live Tooling	Yes (with B-axis)
Max Machining Length	280 mm (11.02 in)
Machine Weight	4,000 kg (8,818 lb)
CNC Control	MAZATROL SmoothG CNC
Max Machining Diameter	Φ1.5"
Max Spindle Speed	8000 min-1(rpm)
Tool Capacity	39

Specifications sourced from mazak.com — verified 2026-03-28

Strengths & Limitations

Strengths

9-axis configuration with true 5-axis contouring through B-axis milling enables complex contoured surfaces and undercuts at the versatile 32 mm bar capacity
7.5 kW main spindle provides the power needed for aggressive cutting in stainless steel, titanium, and Inconel at 32 mm bar diameters
32 mm bar capacity with 5-axis opens up complex medical implants, aerospace fittings, and hydraulic manifold work beyond the 25 mm class
B-axis on the milling spindle enables compound-angle drilling, contoured surface milling, and undercut features directly in the Swiss-type cycle
MAZATROL SmoothG supports both conversational programming for standard operations and full 5-axis G-code for complex contoured work
Eliminates secondary milling operations by completing complex parts in a single Swiss-type cycle with 5-axis contouring capability

Limitations

5-axis contouring requires advanced CAM software (Esprit, GibbsCAM, or similar) and skilled programmers beyond standard Swiss expertise
7,000 RPM spindle speed is lower than smaller SYNCREX models, limiting surface speed on smaller-diameter features within the 32 mm range
Starting price near $300K is significantly above the 32/7 and 32/8 models with the 5-axis capability adding substantial cost
Larger 3.1 x 1.6 meter footprint and 4,000 kg weight take more floor space than conventional Swiss machines in this bar range

Best For

Medical device manufacturers producing complex larger orthopedic implants, hip components, and spinal cages requiring both Swiss-type precision and 5-axis contoured surfaces Aerospace component producers machining turbine fittings, actuator shafts, and fluid system components with compound-angle features from superalloys at 32 mm bar capacity Hydraulic and pneumatic manufacturers machining complex manifold bodies, multi-port valve spools, and fittings that benefit from 32 mm capacity and 5-axis milling High-precision job shops wanting Swiss-type capability combined with multi-tasking 5-axis flexibility for complex parts in the 25-32 mm range Shops consolidating Swiss turning and secondary 5-axis milling into a single machine for larger precision components

Frequently Asked Questions

01 What does a new Mazak SYNCREX 32/9X cost?

Base SYNCREX 32/9X configurations start around $300,000. Fully equipped machines with bar feeder, parts catcher, high-pressure coolant, full live tooling complement, and B-axis milling setup run $380,000-$440,000. The 5-axis capability commands a premium over the standard 32/8 and 32/9 models.

02 How does the SYNCREX 32/9X compare to the 38/9X?

Both share 9-axis 5-axis contouring with B-axis milling. The 38/9X has larger 38 mm bar capacity and slightly more tool positions but costs more and takes more floor space. The 32/9X is better suited when parts fit within the 32 mm bar capacity, as it costs less and has a smaller footprint. Choose the 38/9X only when parts exceed 32 mm diameter.

03 What CAM software works with the SYNCREX 32/9X?

For standard Swiss operations, MAZATROL conversational programming handles most turning, drilling, and simple milling. For 5-axis contouring, dedicated CAM software is required. Esprit (by Hexagon), GibbsCAM, and SOLIDCAM all support the SYNCREX platform. Post processor development may be needed for the 9-axis configuration with B-axis.

04 Can the 32/9X replace a multi-tasking machine for mid-size parts?

For bar-fed parts up to 32 mm diameter, the 32/9X can genuinely replace a small multi-tasking machine while adding Swiss-type rigidity and precision. The 5-axis milling and 9 axes of control bridge the gap between Swiss-type and multi-tasking. However, for parts requiring heavy milling, large work envelopes, or chucked operations on larger diameters, a dedicated multi-tasking machine remains the better choice.
