Mazak INTEGREX i-300

$300,000 - $450,000 Updated 2026-03-16

Key Specifications

X Travel

580 mm (22.8 in)

Y Travel

230 mm (9.06 in)

Z Travel

1,100 mm (43.3 in)

Tool Capacity

36 tools (72 or 110 optional)

max machining diameter

658 mm (25.9 in)

max machining length

1,016 mm (40 in)

Overview

The Mazak INTEGREX i-300 sits between the i-200 and i-400 in Mazak’s multi-tasking lineup, filling the gap for shops that need more bar capacity and spindle torque than the i-200 but not the full envelope of the i-400. It’s a purpose-built 5-axis mill-turn center that consolidates turning, milling, drilling, tapping, and off-center machining into a single clamping.

You get a 658 mm (25.9 in) max machining diameter and 1,016 mm (40 in) max machining length, with a 10-inch chuck and 80 mm (3.15 in) bar capacity through an A2-8 spindle nose. The main turning spindle runs to 4,000 RPM with 26 kW (35 hp), offering more torque than the i-200’s 22 kW but not quite the i-400’s 30 kW, making it a balanced choice for medium-diameter work in steel and alloy materials.

The milling spindle hits 12,000 RPM with 18.5 kW (25 hp) through an HSK-A63 or Capto C6 interface. A 20,000 RPM option is available. The B-axis swings 240 degrees (-30 to +210) with roller cam drive and 0.0001-degree indexing resolution. Y-axis travel measures 230 mm (9.06 in), and the continuous C-axis provides 360-degree rotation.

Axis travels include 580 mm (22.8 in) on X and 1,100 mm (43.3 in) on Z, with rapids hitting 50 m/min (1,969 ipm). The standard 36-tool ATC handles most jobs, with 72 and 110-tool options. Current NEO-generation machines run on MAZATROL SmoothAi with Ai Thermal Shield. The i-300 weighs approximately 12,000 kg (26,455 lb).

The -S variant adds a second spindle, and the -ST adds both a second spindle and lower turret. Competitors include the DMG Mori CTX beta 1250 TC and Okuma Multus B300II. New machines run $300,000-$450,000. Used units from 2014-2020 trade $120,000-$300,000. Specs sourced from Mazak published data.

Full Specifications

Parameter	Value
Max Machining Diameter	658 mm (25.9 in)
Max Machining Length	1,016 mm (40 in)
X-Axis Travel	580 mm (22.8 in)
Y-Axis Travel	230 mm (9.06 in)
Z-Axis Travel	1,100 mm (43.3 in)
B Axis Range	240° (-30° to +210°)
C Axis Rotation	360° continuous
Main Spindle Speed	4,000 RPM
Main Spindle Power	26 kW (35 hp)
Milling Spindle Speed	12,000 RPM (20,000 RPM optional)
Milling Spindle Power	18.5 kW (25 hp)
Milling Spindle Taper	HSK-A63 / Capto C6
Chuck Size	10 in (A2-8)
Bar Capacity	80 mm (3.15 in)
Tool Capacity	36 tools (72 or 110 optional)
Rapid Traverse Xz	50 m/min (1,969 ipm)
Rapid Traverse Y	40 m/min (1,575 ipm)
Machine Weight	12,000 kg (26,455 lb)
CNC Control	MAZATROL SmoothAi CNC

Specifications sourced from mazak.com — verified 2026-03-28

Strengths & Limitations

Strengths

10-inch chuck with 80 mm bar capacity bridges the gap between the i-200’s 65 mm and i-400’s 102 mm for a wider bar stock range
26 kW (35 hp) main spindle with 4,000 RPM provides balanced torque and speed for medium-diameter turning
240-degree B-axis with roller cam drive and 0.0001-degree resolution delivers zero-backlash positioning matching larger models
12,000 RPM HSK-A63 milling spindle delivers true machining center performance for milling, drilling, and tapping
50 m/min rapids keep non-cutting time competitive when cycling between operations
36-tool ATC expandable to 110 tools handles complex aerospace and medical parts
Smaller footprint at 12,000 kg vs 15,500 kg for the i-400 while delivering substantially more capability than the i-200

Limitations

4,000 RPM main spindle is slower than the i-200’s 5,000 RPM, limiting high-speed small-diameter turning
$300K-$450K is significant investment requiring consistent multi-operation parts to justify
Programming complexity is high for simultaneous 5-axis; 3-6 months ramp-up for experienced programmers
12,000 kg requires proper foundation work and rigging
230 mm Y-axis travel is less than the i-400’s 250 mm or e-420H’s 420 mm for off-center work

Best For

Aerospace shops machining flight components needing turning, milling, and drilling with bar stock up to 80 mm Medical device manufacturers where done-in-one processing eliminates contamination risk between operations Job shops where the i-200 is too small but the i-400 is more machine than needed Oil and gas component manufacturers running medium-diameter parts with complex features Production shops running bar feeders up to 80 mm for lights-out multi-tasking

Frequently Asked Questions

01 What does a new i-300 cost?

Base starts around $300,000. Production configs with 20K RPM milling spindle and 72-tool magazine run $370K-$450K. -S/-ST variants add $50K-$120K. Used 2014-2020 units sell $120K-$300K.

02 How does it compare to the i-200 and i-400?

Same 25.9 inch swing but 10-inch chuck and 80 mm bar (vs i-200’s 8 inch/65 mm). Main spindle 4,000 RPM/26 kW, between the i-200’s 5,000/22 kW and i-400’s 3,300/30 kW. Choose when bar stock exceeds 65 mm but you do not need the i-400’s 102 mm or 60 inch length.

03 What are the -S and -ST variants?

Base has single spindle with tailstock. -S adds second turning spindle for back-working. -ST adds second spindle plus lower turret for simultaneous cutting. ST is most capable but most complex to program.

04 Best CAM software?

MAZATROL handles basic work. Complex 5-axis uses Esprit, NX, or Mastercam with custom post processors that are notoriously hard to find for INTEGREX machines.

05 Can it run unattended?

Yes. Pairs with bar feeders up to 80 mm diameter. SmoothAi provides tool life management for extended unmanned operation. -S variant enables both-end processing unattended.
