Matsuura MAM72-42V PC32

$500,000 - $750,000 Updated 2026-03-19

Key Specifications

X Travel

550 mm (21.7 in)

Y Travel

490 mm (19.3 in)

Z Travel

510 mm (20.1 in)

Max Spindle

12,000 RPM (optional 20,000 RPM)

Spindle Taper

BT40 (HSK-A63 optional)

Tool Capacity

60 standard chain (130-530 matrix magazine optional)

Overview

The Matsuura MAM72-42V PC32 is the fully configured production version of the MAM72-42V, shipping with the standard 32-pallet tower stocker that defines the MAM72 platform. While the MAM72-42V base model can be configured with various pallet counts, the PC32 designation explicitly calls out the 32-station configuration that most production shops specify and the configuration where the MAM72 economics make the most sense. With 32 pallets cycling through the machine, a single operator can manage the cell while the spindle cuts continuously for days at a time.

The machining specifications match the MAM72-42V: axis travel of 550 x 490 x 510 mm (21.7 x 19.3 x 20.1 in) on X/Y/Z, with A-axis tilt from +30 to -120 degrees and continuous 360-degree C-axis rotation. Max workpiece size is 420 mm diameter by 315 mm tall (16.5 x 12.4 in) with 80 kg (176 lb) load capacity per pallet. The standard spindle runs a BT40 taper at 12,000 RPM with 11/15 kW (15/20 hp), with 20,000 RPM and HSK-A63 options.

The 32-pallet tower stocker is what makes this machine special. Each station holds a pre-fixtured 420 mm pallet ready for automatic loading. The chain-type tool magazine holds 60 tools standard, with matrix magazine options ranging from 130 to 530 tools — enough tooling variety to support dozens of different part programs across all 32 pallets. Direct-drive rotary axes deliver indexing speeds of 50 min⁻¹ (B-axis) and 100 min⁻¹ (C-axis) for fast positioning between cuts.

The MIMS (Matsuura Intelligent Meister System) cell controller manages pallet priority, tool life, sister tool substitution, and production scheduling. The G-Tech 31i control handles the machining operations. CAMplete TruePath comes standard. The MAM72-42V PC32 weighs approximately 12,000 kg (26,455 lb) with a footprint of roughly 2,900 x 4,200 mm including the pallet stocker. For high-mix production of medical implants, aerospace fittings, and precision industrial components in the 420 mm envelope, this is one of the most productive automated 5-axis cells available from any manufacturer.

Full Specifications

Parameter	Value
X-Axis Travel	550 mm (21.7 in)
Y-Axis Travel	490 mm (19.3 in)
Z-Axis Travel	510 mm (20.1 in)
A Axis Range	+30° to -120°
C Axis Range	360° (continuous)
Max Spindle Speed	12,000 RPM (optional 20,000 RPM)
Spindle Taper	BT40 (HSK-A63 optional)
Spindle Motor Power	11 / 15 kW (15 / 20 hp)
Tool Capacity	60 standard chain (130-530 matrix magazine optional)
Pallet Capacity	32 pallets (tower stocker)
Table Diameter	420 mm (16.5 in)
Max Workpiece Size	420 mm dia x 315 mm H (16.5 x 12.4 in)
Table Load Capacity	80 kg (176 lb) per pallet
Rapid Traverse Xyz	50 m/min (1,969 ipm)
Rotary Indexing Speed	50 / 100 min⁻¹ (B / C axis, direct drive)
Tool Change Time	1.3 sec (tool-to-tool)
Machine Weight	12,000 kg (26,455 lb)
Floor Space Required	2,900 x 4,200 mm (with pallet stocker)
CNC Control	Matsuura G-Tech 31i (FANUC 31i-B5 based, touch screen)
Max Work Size	Φ420×H315mm（Φ16.53×H12.40）
Loading Capacity	80kg（176lb.）
Standard	Tower Pallet System PC32
Option	Matrix Magazine130/170/210/250/290/330 tools370/410/450/490/530 tools

Specifications sourced from matsuura.co.jp — verified 2026-03-28

Strengths & Limitations

Strengths

32-pallet tower stocker enables multi-day unattended production campaigns across dozens of different part setups without operator intervention
Matrix magazine option scales to 530 tools, supporting the full tooling variety needed for high-mix production across all 32 pallets
MIMS cell controller provides intelligent scheduling, tool life management, and sister-tool substitution for truly autonomous operation
Direct-drive rotary axes deliver fast, precise indexing for efficient simultaneous 5-axis contouring
420 mm workpiece diameter covers the sweet spot for mid-sized aerospace fittings and medical implant components
Compact cell footprint of 2.9 x 4.2 m delivers FMS-level automation without the floor space of a standalone flexible manufacturing system

Limitations

80 kg per-pallet load capacity is restrictive for heavier fixtures and larger steel workpieces, limiting fixture design options
BT40 spindle limits aggressive roughing in hard metals — shops cutting heavy titanium and Inconel may need the MAM72-63V with BT50
High upfront cost of $500K-$750K requires genuine high-volume, high-mix production to achieve acceptable ROI
MIMS software and 32-pallet scheduling have a real learning curve — plan for 2-3 months of ramp-up before the cell runs at full efficiency

Best For

Medical device manufacturers running families of orthopedic implants and surgical instruments across dozens of setups in continuous rotation Aerospace tier-1 suppliers machining diverse small structural components with 72+ hours of unattended 5-axis production capability Contract manufacturers that need maximum spindle utilization across high-mix part families without dedicated operator attendance Watch and precision instrument makers who benefit from the 32-pallet system for running large families of small, complex parts Shops scaling from single-pallet or 4-pallet 5-axis machines to genuine cell-level automation for dramatic productivity improvement

Frequently Asked Questions

01 What does a Matsuura MAM72-42V PC32 cost?

New MAM72-42V PC32 pricing typically ranges from $500,000 to $750,000 depending on spindle selection, tool magazine size, and software options. Configurations with 530-tool matrix magazines and HSK spindles can push past $800,000.

02 How many hours can the MAM72-42V PC32 run unattended?

With 32 pallets loaded and typical cycle times of 30 minutes to 2 hours per pallet, the machine can run 16-64 hours unattended depending on part complexity. Medical device shops regularly report 72+ hour weekend runs.

03 What is the difference between the chain magazine and matrix magazine?

The chain magazine holds 60 tools in a simple chain carousel. The matrix magazine uses a grid storage system starting at 130 tools scaling to 530, enabling the machine to hold all tools for dozens of different part programs simultaneously.

04 Can one operator really manage a 32-pallet cell?

Yes. The MIMS controller manages scheduling, tool life, and alerts from a single interface. One skilled operator can manage 2-4 MAM72 cells depending on part changeover frequency.
