GF Machining AgieCharmilles CUT P 1250 Pro

$450,000 - $700,000 Updated 2026-03-19

Key Specifications

X / Y / Z Travel

1250 x 850 x 100-800 mm (49.2 x 33.5 x 3.9-31.5 in)

U / V Travel

1250 x 850 mm (49.2 x 33.5 in)

Max Workpiece Dimensions

2300 x 1300 x 800 mm (90.6 x 51.2 x 31.5 in)

Max Workpiece Weight

6,000 kg (13,228 lb)

Wire Diameter Range

0.15 - 0.33 mm

Min Surface Finish Ra

0.2 µm

Overview

The GF Machining Solutions AgieCharmilles CUT P 1250 Pro is the flagship large-frame production wire EDM in GF's latest CUT P Pro series — the largest and most capable wire EDM in GF's current lineup. With X/Y travels of 1250 x 850 mm, Z-travel up to 800 mm, and a massive 6,000 kg workpiece capacity, the CUT P 1250 Pro handles the largest die plates, mold frames, and industrial components in the wire EDM world.

The 6,000 kg workpiece capacity is the defining specification. This enables complete large die plate assemblies — including guide plate, punch plate, die plate, and stripper — to be wire-cut in a single setup without sectioning. For automotive body die builders and large progressive die shops, this eliminates the accumulation of positioning errors from multiple setups, delivering single-reference-coordinate accuracy across all features on the largest tooling plates.

Maximum workpiece dimensions of 2300 x 1300 x 800 mm accommodate the largest industrial tooling applications. The latest-generation IPG generator achieves Ra 0.2 µm surface finishes on this massive platform while delivering up to 30% daily energy reduction — a significant savings on machines running extended production shifts cutting thick, large-section material. Wire diameter support is 0.15 to 0.33 mm, with 25-45 kg wire spool capacity for maximum unattended run time.

Taper cutting capability reaches 30° over the full 800 mm Z-height. The SMART consumables system and advanced HMI ensure that this industrial-scale machine delivers the same predictive maintenance and operator-friendly experience as smaller CUT P Pro models. The CUT P 1250 Pro serves the most demanding large-die and heavy-industry tooling applications worldwide.

Full Specifications

Parameter	Value
X / Y / Z Travel	1250 x 850 x 100-800 mm (49.2 x 33.5 x 3.9-31.5 in)
U / V Travel	1250 x 850 mm (49.2 x 33.5 in)
Max Workpiece Dimensions	2300 x 1300 x 800 mm (90.6 x 51.2 x 31.5 in)
Max Workpiece Weight	6,000 kg (13,228 lb)
Wire Diameter Range	0.15 - 0.33 mm
Min Surface Finish Ra	0.2 µm
Max Taper Angle	30° / 800 mm
Max Wire Spool Weight	25-45 kg (55-100 lb)
Control System	Advanced HMI with SMART consumables
Generator	Intelligent Power Generator (IPG) — latest generation
Dielectric	Deionized water
Travel X Y Z	1250 x 850 x 100-800 mm49.2 x 33.5 x 3.9-27.56 in
Min Surface Roughness Ra	0.2 μm
Max Taper Angle Height	30°/800 mm30°/31.5 in
Max Workpiece Dimensions	1300 x 950 x 510 mm51.18 x 21.65 x 20.07 in
Max Workpiece Weight	6000 kg13228 lbs
Travel U V	1250 x 850 mm49.2 x 33.5 in
Wire Diameters	0.15-0.33 mm0.006-0.013
Max Wire Spool Weight	25-45 kg55-100 lbs

Specifications sourced from gfms.com — verified 2026-03-28

Strengths & Limitations

Strengths

6,000 kg workpiece capacity enables complete large die plate assemblies in single-setup cutting
1250 x 850 mm travel with up to 800 mm Z-height handles the largest industrial tooling
Latest IPG generator delivers 30% energy savings on extended heavy production cutting
2300 x 1300 mm table accommodates full-size automotive stamping die plates
25-45 kg wire spool capacity ensures maximum unattended run time on large jobs
SMART consumables and advanced HMI maintain production-grade reliability at industrial scale

Limitations

Major capital investment ($450K-$700K) requires high-value, high-volume large-die work to justify
Requires reinforced foundation, heavy overhead crane (6+ tonnes), and significant floor space
Ra 0.2 µm surface finish is coarser than compact precision models — large-frame trade-off
Setup time for crane-loading and fixturing 6,000 kg workpieces is substantial

Best For

Automotive body stamping die builders cutting full-size blanking, trim, and piercing dies Large progressive die manufacturers processing complete die plate assemblies in single setups Extrusion die producers cutting large aluminum and copper extrusion die matrices from hardened stock Aerospace structural tooling shops cutting large forming tools and fixture plates Heavy industrial mold builders processing full-size mold plates and cavity retainer assemblies

Frequently Asked Questions

01 What infrastructure does the CUT P 1250 Pro require?

The CUT P 1250 Pro requires a reinforced concrete foundation (minimum 250-300 mm thick with appropriate rebar), overhead crane capacity of at least 6-7 tonnes for workpiece loading, three-phase industrial electrical supply, and extensive floor space (approximately 6 x 4 meters plus clearance). GF provides detailed site preparation specifications.

02 How does the CUT P 1250 Pro compare to the prior-generation CUT P 1250?

The Pro version features the latest-generation IPG with 30% energy savings, SMART consumables for predictive maintenance, an updated HMI interface, and expanded Z-travel up to 800 mm. The larger workpiece dimensions (2300 x 1300 x 800 mm vs prior generation) and updated wire spool capacity also represent significant improvements.

03 Why is the surface finish Ra 0.2 µm instead of the 0.08 µm achievable on smaller CUT P Pro models?

Large-frame wire EDMs inherently face greater challenges in achieving ultra-fine surface finishes due to longer wire spans, increased flushing distances, and the thermal mass of larger workpieces. Ra 0.2 µm is excellent for large die plates and industrial tooling. Applications requiring finer finishes on smaller features should use the CUT P 550 Pro or CUT P 350 Pro.

04 Can the CUT P 1250 Pro cut carbide workpieces?

Yes. Wire EDM cuts any electrically conductive material. The IPG generator includes carbide-specific parameters. Large carbide workpieces — extrusion die matrices, industrial wear plates — are among the most common applications for large-frame wire EDMs like the CUT P 1250 Pro.
