GF Machining AgieCharmilles CUT 2000 S

$220,000 - $320,000 Updated 2026-03-19

Key Specifications

X / Y / Z Travel

350 x 250 x 256 mm (13.8 x 9.8 x 10.1 in)

U / V Travel

±70 mm (±2.8 in)

Max Workpiece Dimensions

750 x 550 x 250 mm (29.5 x 21.7 x 9.8 in)

Max Workpiece Weight

200 kg (440 lb) with bath

Wire Diameter Range

0.10 - 0.30 mm (0.05-0.07 mm optional)

Min Surface Finish Ra

0.07 µm

Overview

The GF Machining Solutions AgieCharmilles CUT 2000 S is a high-performance compact wire EDM engineered for superior surface finish quality in precision die, mold, and micro-component manufacturing. As the surface-finish-optimized model in GF's CUT 2000/3000 series, the CUT 2000 S leverages GF's proven Intelligent Power Generator (IPG) technology to achieve mirror-class surface finishes down to Ra 0.07 µm, making it one of the finest-finishing wire EDMs available in its travel class.

With X/Y/Z travels of 350 x 250 x 256 mm and U/V travel of ±70 mm, the CUT 2000 S targets the precision end of compact wire EDM work: injection mold inserts, medical device tooling, watch components, connector tooling, and micro-feature profiles. The 200 kg maximum workpiece weight (with bath) keeps the machine focused on precision small-part work rather than heavy die plates.

The IPG generator on the CUT 2000 S is specifically tuned for surface quality optimization. By delivering ultra-fine spark discharge pulses with precise energy control, the generator achieves Ra 0.07 µm finishes in multi-pass skim cutting sequences — a level of surface quality that eliminates hand polishing on many precision mold cavity surfaces. The machine supports wire diameters from 0.10 to 0.30 mm, with optional capability down to 0.05-0.07 mm micro-wire for the finest detail work.

Taper cutting capability of ±30° over 100 mm workpiece height covers the full range of die-clearance angles and reverse-taper geometries required in progressive die and stamping tool applications. The AC CUT HMI control provides GF's comprehensive technology database with automatic parameter selection based on material, wire diameter, and target surface finish.

Full Specifications

Parameter	Value
X / Y / Z Travel	350 x 250 x 256 mm (13.8 x 9.8 x 10.1 in)
U / V Travel	±70 mm (±2.8 in)
Max Workpiece Dimensions	750 x 550 x 250 mm (29.5 x 21.7 x 9.8 in)
Max Workpiece Weight	200 kg (440 lb) with bath
Wire Diameter Range	0.10 - 0.30 mm (0.05-0.07 mm optional)
Min Surface Finish Ra	0.07 µm
Max Taper Angle	±30° / 100 mm height
Max Wire Spool Weight	25 kg
Control System	AC CUT HMI with IPG technology
Generator	Intelligent Power Generator (IPG)
Dielectric	Deionized water
Travel X Y Z	350 x 250 x 256 mm13.77 x 9.84 x 10 in
Min Surface Roughness Ra	0.05 μm2 μin
Max Taper Angle Height	± 30°/100 mm± 30°/3.93 in
Max Workpiece Dimensions	750 x 550 x 250 mm29.5 x 21.6 x 9.8 in
Max Workpiece Weight	200 kg
Travel U V	± 70 mm± 2.7 in
Wire Diameters	0.10 - 0.30 (0.05-0.07 optional) mm0.004 - 0.012 (0.002-0.003 optional) in
Max Wire Spool Weight	25 kg55.11 lbs

Specifications sourced from gfms.com — verified 2026-03-28

Strengths & Limitations

Strengths

Mirror-class surface finish down to Ra 0.07 µm eliminates hand polishing on precision mold surfaces
Intelligent Power Generator (IPG) optimizes spark discharge for maximum surface quality with minimal wire consumption
Optional micro-wire capability (0.05-0.07 mm) enables ultra-fine detail and micro-feature cutting
Wide ±30° taper angle supports complex die-clearance and reverse-taper geometries
AC CUT HMI with comprehensive technology database reduces operator learning curve
GF Machining Solutions global service network ensures responsive support worldwide

Limitations

200 kg workpiece weight limit restricts use to smaller precision components only
350 x 250 mm X/Y travel limits workpiece size compared to CUT 3000 series
Premium pricing reflects GF's high-end positioning in the wire EDM market
Advanced options (AWC, micro-wire) add significantly to base machine cost

Best For

Precision injection mold insert manufacturers requiring mirror-quality surface finishes Medical device and watch component tooling with micro-feature requirements Connector and electronics tooling shops cutting fine-pitch profiles Die shops where eliminating hand polishing reduces lead time and cost Micro-EDM applications using 0.05-0.07 mm wire for ultra-fine detail work

Frequently Asked Questions

01 What is the difference between the CUT 2000 S and CUT 2000 X?

Both machines share identical physical specifications and travel dimensions. The CUT 2000 X adds laser-calibrated positioning accuracy down to ±1.5 µm total positioning accuracy, making it the choice for applications where absolute dimensional accuracy is the top priority. The CUT 2000 S focuses on surface finish optimization with Ra 0.07 µm capability.

02 Can the CUT 2000 S cut with micro-wire below 0.10 mm?

Yes, with the optional micro-wire package, the CUT 2000 S supports wire diameters down to 0.05-0.07 mm. This enables cutting of extremely fine internal corner radii, micro-slots, and precision profiles that standard 0.10 mm wire cannot achieve. Cutting speed decreases proportionally with thinner wire.

03 What materials can the CUT 2000 S cut?

The CUT 2000 S cuts any electrically conductive material including hardened tool steels, carbide, PCD (polycrystalline diamond), titanium, Inconel, copper, and aluminum. The IPG generator includes optimized parameters for each material type in the AC CUT technology database.

04 How does the CUT 2000 S compare to the CUT 2000 OilTech?

The CUT 2000 OilTech uses oil-based dielectric instead of deionized water, achieving even finer surface finishes down to Ra 0.05 µm. Oil dielectric also eliminates workpiece corrosion risk on steel parts. The standard CUT 2000 S uses deionized water and achieves Ra 0.07 µm, with faster cutting speeds than oil-based EDM.
