Sodick Sodick EXC100L+
Key Specifications
X Travel
Y Travel
Z Travel
uv travel
max workpiece dimensions
max workpiece weight
Overview
The Sodick EXC100L+ is an ultra-precision micro wire EDM from the EXC series, offering 100 x 120 x 100 mm X/Y/Z travel for the finest wire EDM work available. Supporting wire diameters from 0.02 to 0.10 mm, the EXC100L+ operates in the micro-machining domain where features measured in tens of microns are routine. This is not a conventional wire EDM; it is a specialized micro-machining platform for medical device components, semiconductor tooling, MEMS structures, watch components, and applications where dimensional tolerances below 1 micron are required.
The EXC100L+ supports a maximum workpiece of just 150 x 150 x 60 mm and 10 kg, reflecting its exclusive focus on small, high-precision components. The 0.02 mm (20 micron) minimum wire diameter enables slot widths and feature geometries physically impossible on standard wire EDMs with 0.10 mm minimum wire. At these wire diameters, discharge energy must be controlled with extreme precision to prevent immediate wire breakage.
Wire tension range of 0.5 to 10 N is calibrated for micro-wire operation, far lower than the 3-25 N range on standard Sodick wire EDMs. Maximum taper of plus/minus 6 degrees at 60 mm plate thickness provides adequate angular capability for micro-component applications. The EXC100L+ includes linear motor positioning on all axes.
At 2,500 kg total weight (including power supply and relay box) and 2,250 x 2,290 mm footprint (2,850 x 2,900 mm installation space), the EXC100L+ is compact. Three-phase 9 kVA power is required.
Full Specifications
| Parameter | Value |
|---|---|
| X-Axis Travel | 100 mm (3.9 in) |
| Y-Axis Travel | 120 mm (4.7 in) |
| Z-Axis Travel | 100 mm (3.9 in) |
| Uv Travel | 20 x 20 mm |
| Max Workpiece Dimensions | 150 x 150 x 60 mm (5.9 x 5.9 x 2.4 in) |
| Max Workpiece Weight | 10 kg (22 lb) |
| Max Taper Angle | ±6°（plate thickness：60mm） |
| Wire Diameter Range | 0.02 - 0.10 mm |
| Wire Tension | 0.5 ～ 10 |
| Max Wire Feed Rate | 250 mm/sec |
| Drive System | Linear motors (all axes) |
| CNC Control | Sodick LQ controller |
| Machine Dimensions | 2,250 x 2,290 x 1,990 mm (88.6 x 90.2 x 78.3 in) |
| Installation Footprint | 2,850 x 2,900 mm (112.2 x 114.2 in) |
| Machine Weight | 2,500 kg (5,512 lb) including power supply and relay box |
| Power Supply | 3-phase 50/60 Hz 9 kVA |
| Axis Stroke Xyz | 100 x 120 x 100 |
| U X V Axis Travel | 20 x 20 |
| Max Workpiece Dimensionsduring Flushing Machiningw X D X H | 150 x 150 x 60 |
| Max Weight Of Workpieceduring Flushing Machiningkg | 10*1 |
| Wire Electrode Diameter | 0.02 ～ 0.1 |
| Maximum Wire Feed Rate | 250 |
| Distance From Floor Surface To Upper Surface Of Table | 1050 |
| Machine Tool Dimensions W X D X H | 2250 x 2290 x 1990*2 |
| Machine Installation Dimensions W X D | 2850 x 2900 |
| Total Unit Weightkg | 2500*3 |
| Total Power Input | 3-phase 50/60Hz 9 kVA |
