DN Solutions DCM-U 5040
Key Specifications
X Travel
Y Travel
Z Travel
Max Spindle
Spindle Taper
Tool Capacity
Overview
The DN Solutions DCM-U 5040 is a large-format 5-axis double-column machining center that combines the rigidity of a gantry-type structure with full simultaneous 5-axis capability through a universal milling head. The machine features a movable W-axis crossrail with travel of approximately 4,250 x 3,200 x 1,000 mm (167 x 126 x 39 in) on X/Y/Z, plus A and C rotary axes in the universal head that enable full 5-axis contouring on workpieces far too large for conventional trunnion-table 5-axis machines.
The universal automatic head is the centerpiece of the DCM-U platform. The A-axis tilts through a range of ±105 degrees while the C-axis rotates a full 360 degrees continuously, giving the spindle access to virtually any surface angle on the workpiece. This head-head 5-axis configuration keeps the workpiece stationary on the table, which is critical when machining parts weighing 15,000-20,000 kg — rotating a workpiece of that mass on a trunnion would be impractical.
The spindle delivers 37 kW (50 hp) at speeds up to 6,000 RPM through a CAT 50 / BT 50 taper in the standard configuration. High-speed spindle options up to 12,000 or 24,000 RPM are available for aerospace aluminum and composite work, typically with HSK-A63 or HSK-A100 tapers. Rapid traverse of 12 m/min (472 ipm) on linear axes and rotary axis speeds suited to large-part contouring keep the machine productive despite its massive scale.
The table spans approximately 5,000 x 3,000 mm (197 x 118 in) with a load capacity of 20,000 kg (44,092 lb). At roughly 80,000 kg (176,370 lb), the DCM-U 5040 requires extensive foundation preparation. The FANUC 31iB5 or Siemens 840D control provides the 5-axis kinematic transformations and RTCP (Rotation Tool Center Point) functionality essential for accurate 5-axis contouring. The DCM-U 5040 competes with the Pama Speedmat, Soraluce FMT, Jobs LinX, and Waldrich Coburg in the large 5-axis double-column segment.
Full Specifications
| Parameter | Value |
|---|---|
| X-Axis Travel | 4,250 mm (167 in) |
| Y-Axis Travel | 3,200 mm (118 in) |
| Z-Axis Travel | 1,000 mm (39 in) |
| Travel W | 2,500 mm (98 in) crossrail |
| A Axis Range | ±105° |
| C Axis Range | 360° (continuous) |
| Max Spindle Speed | 6,000 RPM (12,000 / 24,000 RPM optional) |
| Spindle Motor Power | 37 kW (50 hp) |
| Spindle Taper | CAT 50 / BT 50 (HSK-A63/A100 optional) |
| Crossrail Type | Movable W-axis crossrail |
| Universal Head | Automatic A/C universal milling head |
| Table Size | 5,000 x 3,000 mm (197 x 118 in) |
| Table Load Capacity | 20,000 kg (44,092 lb) |
| Rapid Traverse Xyz | 12 m/min (472 ipm) |
| Tool Capacity | 40 (expandable to 60/80/120) |
| Machine Weight | 80,000 kg (176,370 lb) |
| Guideway Type | Box guideways with roller packs |
| CNC Control | FANUC 31iB5 / Siemens 840D |
| X Axis Travel Distance | 5250mm |
| Y Axis Travel Distance | 3200mm |
| Z Axis Travel Distance | 1000mm |
| Metric | IMPERIAL |
Specifications sourced from dn-solutions.com — verified 2026-03-28
Strengths & Limitations
Strengths
- Full simultaneous 5-axis capability on workpieces up to 20,000 kg — impossible on conventional trunnion-table 5-axis machines at this scale
- Universal A/C head with ±105° tilt and 360° rotation provides access to virtually any surface angle without re-fixturing
- Double-column gantry construction delivers the rigidity needed for heavy 5-axis contouring in steel and cast iron at large scale
- Multiple spindle options from 6,000 RPM heavy-duty to 24,000 RPM high-speed cover everything from steel roughing to aluminum finishing
- Head-head 5-axis configuration keeps heavy workpieces stationary, eliminating the dynamic challenges of rotating massive parts
Limitations
- 80,000 kg machine weight and large footprint require major foundation engineering and significant facility investment
- Capital cost of $1.5M-$3M puts this machine firmly in the heavy-industry capital equipment category
- Universal head mechanics add maintenance complexity compared to fixed-spindle 3-axis double-column machines
- 6,000 RPM standard spindle is limiting for high-speed aluminum work — higher-speed spindle options add significant cost
Best For
Frequently Asked Questions
01
A new DCM-U 5040 typically ranges from $1,500,000 to $3,000,000 depending on spindle configuration, control platform, head type, and automation. A base configuration with standard 6,000 RPM spindle and FANUC control starts around $1,500,000. High-speed spindle options, Siemens 840D control, extended tool magazines, and probing packages push toward $2,500,000-$3,000,000. Used DCM-U machines are rarely available on the secondary market.
02
The DCM-U 5040 adds a universal A/C milling head for full 5-axis capability, while the DBM 5040 is a 3-axis machine with a fixed ram spindle. The DCM-U also typically uses a more advanced control (FANUC 31iB5 or Siemens 840D vs FANUC 0i-Plus) with 5-axis kinematic transformations and RTCP. The DCM-U commands a significant price premium for the universal head and 5-axis control functionality.
03
DN Solutions offers several head configurations for the DCM-U series. The standard automatic universal head provides A/C axis rotation with torque motor drives. Options include high-speed heads (up to 24,000 RPM with HSK-A63) for aluminum and composite work, and high-torque heads for heavy steel and titanium cutting. Some configurations support automatic head changing between different head types for maximum flexibility.
04
Yes, the DCM-U 5040 supports full simultaneous 5-axis contouring with RTCP (Rotation Tool Center Point) functionality. The A and C axes in the universal head move continuously and simultaneously with the X, Y, and Z linear axes. This is essential for machining complex 3D surfaces like turbine blades, impellers, and sculptured mold surfaces. The FANUC 31iB5 and Siemens 840D controls both handle the kinematic transformations required for accurate 5-axis interpolation.
