Chiron FZ 08 FX
Key Specifications
X / Y / Z Travel
Table Size
Max Workpiece Diameter
Max Workpiece Height
Spindle Speed (max)
Spindle Taper
Overview
The Chiron FZ 08 FX is a compact, high-speed 5-axis machining center engineered specifically for the dental, medical device, and precision micro-component industries. Its small footprint belies impressive dynamic capability, with the FX configuration offering simultaneous 5-axis interpolation optimized for complex contoured parts in titanium, cobalt-chrome, zirconia, and PEEK — all materials central to implantology and orthopedic manufacturing.
The FZ 08 FX inherits Chiron's proven FZ platform architecture but is scaled to accommodate workpiece diameters up to 80 mm, making it ideal for dental prosthetics, surgical instrument blanks, and miniature aerospace components. The integrated A/C-axis tilting rotary table provides full 5-axis simultaneous motion with a compact interface suited to medical-grade fixturing systems.
Chiron's direct-drive spindle technology on the FZ 08 FX delivers speeds up to 42,000 rpm with minimal runout, enabling fine-detail finishing on complex anatomical geometries without secondary operations. The machine's thermal management system maintains spindle growth to under 1 µm/°C, critical for holding tight tolerances on implant contact surfaces.
As part of Chiron's automation-ready ecosystem, the FZ 08 FX integrates directly with the Chiron PartMaster pallet handling system and robot cell interfaces, enabling lights-out production of small batches in regulated industries. Its stainless-steel work envelope and media-sealed enclosure support clean-room-adjacent operation and easy decontamination protocols required in medical manufacturing environments.
Full Specifications
| Parameter | Value |
|---|---|
| X / Y / Z Travel | 320 mm / 280 mm / 350 mm |
| Table Size | ø 200 mm |
| Max Workpiece Diameter | ø 80 mm |
| Max Workpiece Height | 100 mm |
| Spindle Speed (Max) | 42,000 rpm |
| Spindle Taper | HSK-E32 |
| Feed Rate (Max) | 60 m/min |
| A-Axis Range | +30° / -110° |
| C-Axis Range | 360° (continuous) |
| Tool Magazine Capacity | 30 tools |
| Machine Footprint | 1,500 mm × 1,900 mm |
| CNC Control | Siemens Sinumerik ONE |
| Lowest Price | Price |
| Highest Price | Price |
| Newest Listings | Release date |
| Oldest Listings | Release date |
| Shortest Distance | Distance |
| Farthest Distance | Distance |
| Newest Year Of Manufacture | Year of construction |
| Oldest Year Of Manufacture | Year of construction |
| Latest Update | Update |
| Oldest Update | Update |
| Manufacturer A To Z | Manufacturer |
| Manufacturer Z To A | Manufacturer |
| Designation From A To Z | Description |
| Designation From Z To A | Description |
| Model From A To Z | Model |
| Model From Z To A | Model |
| Lowest Reference | Ref.No. |
| Highest Reference | Ref.No. |
| Shortest Runtime | Runtime |
| Longest Duration | Runtime |
| Relevance | Relevance |
| Modelfz18 Fxbrandchirontypevertical Machining Centers Controlcontact Sales Rep | Contact Sales Rep. |
| Modelfz18 Fxbrandchirontypevertical Machining Centers Control | Contact Sales Rep. |
| Model | FZ18 FX |
| Brand | CHIRON |
| Type | Vertical Machining Centers (5-Axis or More) |
| X2874y21654z24803 Axis5 | Power87.2 hpRPM20,000 RPMTaperSK 40 / HSK 63ControlCNC |
| X | 28.74" |
| Y | 21.654" |
| Z | 24.803" |
| Axis | 5 |
| Power | 87.2 hp |
| Rpm | 20,000 RPM |
| Taper | SK 40 / HSK 63 |
| Cnc Control | CNC |
| Looking To Purchase A New Chiron Fz18 Fx | Contact Sales Rep. |
| State Machine Tool Co Incn56 W16743 Ridgewood Drivemenomonee Falls Wisconsin 53051united States | Gadra de MexicoAv. Tercera N0. 855Nazario Ortiz GarzaSaltillo, Coahuila de Zaragoza 25100Mexico |
| Asset Tradeam Sonnenhof 16krefeld Nordrhein Westfalen 47800germany | Centrum CNCKonopnickiej 9/7Kedzierzyn-Kozle 47-200Poland |
Specifications sourced from machinetools.com — verified 2026-03-28
Strengths & Limitations
Strengths
- Ultra-compact footprint ideal for space-constrained dental and medical labs
- 42,000 rpm direct-drive spindle excels on titanium, zirconia, and PEEK
- Full simultaneous 5-axis capability on workpieces up to ø 80 mm
- Stainless-steel enclosure and sealed guideways support clean-room-adjacent operation
- Automation-ready for lights-out production via Chiron PartMaster and robot interfaces
Limitations
- Limited workpiece envelope restricts use to small components only
- HSK-E32 taper limits tool selection compared to larger HSK-A63 platforms
- Premium price point relative to 4-axis dental milling alternatives
Best For
Frequently Asked Questions
01
The FZ 08 FX is optimized for dental and medical materials including grade 5 titanium (Ti-6Al-4V), cobalt-chrome alloys, zirconia (dry milling), PEEK, and stainless steels. Its 42,000 rpm spindle also handles aluminum and engineering plastics efficiently.
02
Yes. The FZ 08 FX is purpose-built for dental and medical manufacturing. Its compact footprint, high-speed spindle, and 5-axis capability allow production of crowns, bridges, abutments, and surgical guides. Automation options support unattended overnight runs.
03
The FZ 08 FX is specifically configured for dental and medical applications with a smaller maximum workpiece diameter (ø 80 mm vs. ø 160 mm on the FZ 08 S), a higher spindle speed (42,000 rpm), and a stainless-steel sealed enclosure. The FZ 08 S is a broader-purpose 5-axis platform.
04
Chiron offers the PartMaster pallet handling system and standardized robot cell interfaces for the FZ 08 FX. These enable automated loading of blank discs or puck-style workpieces, supporting extended unmanned production runs common in dental labs.
05
The FZ 08 FX runs on the Siemens Sinumerik ONE CNC, providing advanced 5-axis interpolation cycles, digital twin capability via Siemens Run MyVirtual Machine, and seamless integration with CAM systems such as hyperMILL, Mastercam Dental, and DentMILL.
