Chiron DZ 25 S Five Axis

$700,000 - $1,000,000 Updated 2026-03-16

Key Specifications

X Travel

830 mm (32.7 in) per spindle

Y Travel

630 mm (24.8 in)

Z Travel

630 mm (24.8 in)

Max Spindle

20,000 RPM standard (up to 40,000 RPM optional)

Spindle Taper

HSK-A63 standard (HSK-A100 optional)

Tool Capacity

Up to 2 x 77 tools

Overview

The Chiron DZ 25 S Five Axis is the 5-axis simultaneous-capable variant of Chiron's largest twin-spindle production platform, combining the Series 25 work envelope with the S-type swivel-head configuration for full 5-axis contouring on both spindles. The "DZ" designation confirms twin-spindle (Doppelspindel) configuration, and the "S" indicates the swivel-head layout that places the A and C rotary axes at each spindle rather than a fixed tilt-rotary table. The 800 mm spindle distance is a defining characteristic of the Series 25 platform, separating it from the tighter spindle spacing of the Series 15 and 16 twin-spindle machines.

The DZ 25 S Five Axis provides X/Y/Z travels of approximately 830 x 630 x 630 mm per spindle. Each spindle operates with independent X and Z axis control, meaning one spindle can perform a tool change while the other continues cutting — a significant non-cutting time reduction compared to machines where both spindles share all axes. This independent axis capability combined with twin-spindle simultaneous machining creates a throughput advantage that is difficult to match with conventional 5-axis machining centers.

Spindle options include 20,000 RPM HSK-A63 for high-speed aluminum and general precision work, and HSK-A100 with up to 400 Nm torque for demanding materials. The mineral-cast machine bed, linear direct drives on all linear axes, and direct drives on both A and C rotary axes per spindle deliver the dynamics and thermal stability required for tight-tolerance production. Tool magazines hold up to 2 x 77 tools. The machine handles workpieces up to 1,000 mm diameter and 500 kg.

The DZ 25 S Five Axis runs on Siemens SINUMERIK 840D sl and can be integrated with automation systems for further spindle utilization gains. Competing platforms include the Heller HF 5500, Grob G750T, and large production machining centers from MAG. New DZ 25 S Five Axis machines typically price between $700,000 and $1,000,000, reflecting the twin-spindle independent axis platform and 5-axis simultaneous capability.

Full Specifications

Parameter	Value
X-Axis Travel	830 mm (32.7 in) per spindle
Y-Axis Travel	630 mm (24.8 in)
Z-Axis Travel	630 mm (24.8 in)
Max Spindle Speed	20,000 RPM standard (up to 40,000 RPM optional)
Spindle Taper	HSK-A63 standard (HSK-A100 optional)
Spindle Torque	Up to 400 Nm (295 ft-lb) with HSK-A100 option
Spindle Configuration	Twin-spindle (DZ) with independent X and Z axes
Spindle Distance	800 mm (31.5 in)
A Axis Range	Direct drive swivel axis per spindle
C Axis Range	360° continuous direct drive per spindle
Max Workpiece Diameter	1,000 mm (39.4 in)
Max Workpiece Weight	500 kg (1,102 lb)
Tool Capacity	Up to 2 x 77 tools
Axis Drives	Linear direct drives on X, Y, Z; direct drives on A, C
Machine Bed	Mineral cast
CNC Control	Siemens SINUMERIK 840D sl
Thermal Management	Water-cooled drives on all axes and spindles
English	Greek
Chiron	Î§ÎµÎ¯ÏÏÎ½ (translit. CheÃrÅn)
Phonetic	IPA
Kahy Ron	/ËkaÉª rÉn/
Father	Mother
Cronus	Philyra
Brothers	Sisters
Hadeszeusposeidon	HeraDemeterHestia
Daughters	Son
Endeishippoocyrhoe	Carystus

Specifications sourced from machinetools.com — verified 2026-03-28

Strengths & Limitations

Strengths

Twin-spindle with 800 mm spindle distance machines two large identical parts simultaneously, delivering exceptional throughput on medium-to-large 5-axis components
Independent X and Z axis control per spindle allows tool changes on one side while the other cuts, reducing non-cutting time beyond standard twin-spindle machines
Full simultaneous 5-axis on both spindles enables complex contoured surfaces, compound angles, and undercuts in a single setup on each part
Up to 1,000 mm workpiece diameter and 500 kg capacity handles parts well beyond the capacity of Series 15 and 16 twin-spindle machines
Linear direct drives on all linear axes with direct drives on all rotary axes provide zero-backlash dynamics across the full twin-spindle platform
Mineral-cast bed and water-cooled drives deliver the thermal stability required for tight-tolerance production on large, complex workpieces

Limitations

Starting price around $700,000 demands high-volume production of large identical 5-axis parts to justify the investment over a single-spindle FZ 22 S
Both spindles execute the same 5-axis program on identical parts — there is no flexibility to machine different parts on each spindle
Large machine footprint and mass require significant factory preparation, including reinforced foundations and overhead crane access
Chiron's North American service network for large twin-spindle 5-axis machines is less extensive than competing European and Japanese manufacturers
Programming 5-axis simultaneous paths for two synchronous spindles demands skilled CAM expertise and careful fixture engineering

Best For

Automotive OEMs running high-volume 5-axis production of large powertrain components, structural castings, and suspension elements Aerospace manufacturers producing large aluminum monolithic structures at production rates where twin-spindle throughput directly drives program economics Heavy equipment and off-highway manufacturers machining large valve bodies, hydraulic manifolds, and structural components in 5-axis at volume Tier-1 automotive suppliers producing identical large 5-axis parts at sustained high volumes where cost per part is the primary metric EV manufacturers machining large aluminum battery housings, motor housings, and structural castings requiring 5-axis contouring at scale Defense contractors producing large, identical 5-axis precision components where both spindles running identical programs ensures output targets

Frequently Asked Questions

01 What does a new Chiron DZ 25 S Five Axis cost?

New DZ 25 S Five Axis machines typically price between $700,000 and $1,000,000 depending on spindle configuration, tool magazine size, and automation options. The twin-spindle independent axis platform with simultaneous 5-axis capability on both sides commands a significant premium over single-spindle 5-axis alternatives.

02 How does the DZ 25 S Five Axis differ from the DZ 25S?

Both share the Series 25 twin-spindle platform with 800 mm spindle distance and independent X/Z axes. The DZ 25 S Five Axis adds simultaneous 5-axis swivel-head capability to both spindles, enabling complex contouring operations that the 3-axis DZ 25S cannot perform. The Five Axis variant costs more and is used where 5-axis contouring is required on large production parts.

03 How does independent X and Z axis control work?

Each spindle on the DZ 25 S Five Axis has its own X and Z axis drive, separate from the shared Y axis. This allows one spindle to retract and perform a tool change via the pick-up magazine while the other spindle continues cutting with no interruption. The result is lower non-cutting time per cycle compared to machines where both spindles share all three linear axes.

04 What automation is compatible with the DZ 25 S Five Axis?

Chiron integrates pallet changers and robotic loading systems with the DZ 25 S Five Axis. Given the twin-spindle configuration with 800 mm spindle spacing, automation systems load both fixture positions simultaneously. Extended pallet pools allow for lights-out or minimally attended operation on high-volume programs. The DZ 25 P is the pallet-changer-standard variant of the same platform.

05 Is the DZ 25 S Five Axis suitable for titanium production?

Yes, with the HSK-A100 torque spindle option delivering up to 400 Nm. The rigid twin-spindle gantry construction and mineral-cast bed provide the stiffness for titanium cutting forces. For sustained high-volume titanium production, the independent axis design helps maintain throughput by minimizing tool change interruptions during long cutting cycles.
