Biesse Rover A FT

$120,000 – $280,000 Updated 2026-03-17

Key Specifications

Working Area (X×Y×Z)

4,900 × 1,620 × 250 mm

Spindle Power

12 kW

Max Spindle Speed

24,000 RPM

Feed Rate

Up to 80,000 mm/min (rapid); 25,000 mm/min (cutting)

Positioning Accuracy

±0.1 mm

Control System

Biesse BiesseWorks / Siemens NC

Overview

The Biesse Rover A FT is a CNC processing center from Biesse Group, the Italian woodworking technology leader, designed for flexible through-feed and point-to-point panel processing in furniture manufacturing and cabinet production environments. The Rover A FT combines the continuous feeding productivity of a through-feed machine with the versatility of a CNC routing center, enabling manufacturers to run panel batches efficiently without the setup interruptions of conventional point-to-point machines.

Biesse's Rover A FT uses a pod and rail worktable with configurable vacuum pods and mechanical stops to hold panels and solid wood components securely during routing, drilling, and shaping operations. The moving gantry traverses the fixed workpiece, while the multi-axis routing unit handles complex profiles, mortises, edge shaping, and decorative routing in a single pass. Biesse's electrospindle delivers consistent cutting quality across material density variations common in furniture panel stock.

The machine integrates with Biesse's BiesseWorks CAD/CAM software, allowing furniture designers to import designs directly from CAD and generate machining programs without manual G-code programming. Nesting optimization is built into the software workflow, maximizing material utilization and reducing waste on sheet goods — a key economic driver for high-mix furniture production.

The Rover A FT is widely deployed in mid-size to large furniture factories, kitchen producers, and custom joinery shops where the combination of flexibility and throughput justifies the investment. Biesse's network of showrooms and technical centers across North America, Europe, and Asia provides rapid application support, training, and service response.

Full Specifications

Parameter	Value
Working Area (X×Y×Z)	4,900 × 1,620 × 250 mm
Spindle Power	12 kW
Max Spindle Speed	24,000 RPM
Feed Rate	Up to 80,000 mm/min (rapid); 25,000 mm/min (cutting)
Positioning Accuracy	±0.1 mm
Control System	Biesse BiesseWorks / Siemens NC
Table Type	Pod and rail vacuum system
Machine Weight	Approx. 4,200 kg

Specifications sourced from biesse.com — verified 2026-03-28

Strengths & Limitations

Strengths

Pod and rail system enables fast setup changes for mixed panel sizes
BiesseWorks software integrates CAD import and nesting optimization
Compact footprint relative to working envelope for smaller factory floors
Biesse's global support and training network reduces downtime risk

Limitations

Z-axis clearance limits to thin-to-medium panel stock — not for thick solid timber
Vacuum workholding less effective on very small panel offcuts
Lower rigidity compared to dedicated metal machining centers — wood and composites only

Best For

Furniture cabinet carcass and door panel routing and drilling Kitchen and bathroom cabinet manufacturers running high mix, medium volume Custom joinery shops machining solid wood and panel components

Frequently Asked Questions

01 What is the difference between the Biesse Rover A FT and a standard Rover A?

The FT (feed-through) variant is optimized for continuous part feeding and batch processing, while the standard Rover A is a more conventional point-to-point configuration. The FT excels in high-throughput batch runs of similar-sized panels.

02 Can the Rover A FT process solid wood as well as panel products?

Yes. The pod and rail workholding system securely holds solid wood components as well as sheet panel materials, making the Rover A FT suitable for furniture manufacturers running both panel and solid wood products on the same machine.

03 What CAD/CAM software works with the Biesse Rover A FT?

Biesse's BiesseWorks software is the native platform and offers the deepest integration including nesting and direct design import. The machine also accepts G-code from third-party CAM software for shops already invested in other platforms.
