SCM Record 220

$180,000 - $380,000 Updated 2026-03-17

Key Specifications

X-Axis Travel

2,200 mm (standard) / up to 6,000 mm with extended bed

Y-Axis Travel

1,300 mm

Z-Axis Travel

300 mm

5-Axis Head

A-axis ±120°, C-axis 360° continuous

Spindle Speed

Up to 24,000 rpm

Spindle Power

Up to 12 kW

Overview

The SCM Record 220 is a high-performance CNC machining center from SCM Group — one of Italy's largest woodworking machinery manufacturers — designed for the production of complex solid wood and engineered wood components used in furniture, staircases, windows, doors, and architectural joinery. The Record 220 occupies the upper end of SCM's router lineup, aimed at manufacturers who need to machine curved, shaped, and 3D-profiled solid wood parts with consistent precision across high production volumes. It combines a robust welded steel gantry with high-speed linear drives and a multi-axis working unit capable of both routing and drilling operations in a single setup.

The machine's working unit is central to its capability: the Record 220 typically features a 5-axis head (or configurable multi-axis unit) that allows simultaneous contouring along complex curved surfaces — essential for chair legs, staircase balusters, window sash profiles, and decorative furniture components where the wood grain and profile must align precisely. SCM's interpolated 5-axis control keeps the tool normal to the surface across compound curves, reducing scallop height and the hand-finishing work required afterward. A vertical electrospindle with speeds up to 24,000 rpm handles both heavy roughing passes removing large amounts of material and fine finishing passes that leave a surface ready for sanding or finishing directly.

SCM integrates the Record 220 with its Maestro CNC software platform, which includes dedicated strategies for solid wood machining including grain-direction-aware toolpath generation, automatic feed rate modulation based on wood density zones (knots and grain changes), and nesting for optimizing board utilization. Maestro connects with major furniture design software and CAD/CAM platforms, and an offline programming station allows production engineers to program complex component families without tying up the machine. The machine's automatic tool changer — holding 12 to 48 tools depending on configuration — enables complex multi-operation programs without operator intervention.

For manufacturers with high production volumes, the Record 220 can be configured with an integrated pallet system or automatic workpiece handling to enable lights-out operation of repetitive component families. SCM's proprietary vacuum pods and clamping system accommodates irregular solid wood blanks that cannot be held flat on a standard vacuum table, making the machine suitable for processing natural wood boards with warp, bow, or irregular shapes. This combination of 5-axis machining, solid wood-specific software, and flexible work-holding positions the Record 220 as a premium choice for bespoke furniture manufacturers and architectural millwork shops serving high-end residential and commercial fit-out markets.

Full Specifications

Parameter	Value
X-Axis Travel	2,200 mm (standard) / up to 6,000 mm with extended bed
Y-Axis Travel	1,300 mm
Z-Axis Travel	300 mm
5-Axis Head	A-axis ±120°, C-axis 360° continuous
Spindle Speed	Up to 24,000 rpm
Spindle Power	Up to 12 kW
Rapid Feed Rate	Up to 60 m/min
Tool Magazine Capacity	12 – 48 tools (ATC configuration)
Work-Holding	Vacuum pods + lateral clamps (automatic positioning)
Drilling Unit	Vertical + horizontal spindles (optional aggregate)
CNC Control	SCM Maestro
Compatible Materials	Solid wood, MDF, plywood, engineered wood composites

Strengths & Limitations

Strengths

5-axis simultaneous contouring enables complex curved solid wood profiles (chair legs, balusters, window sash) in a single setup
SCM Maestro software includes wood-specific strategies such as grain-direction toolpaths and automatic feed rate adaptation for density variations
Automatic vacuum pod positioning handles irregular solid wood blanks with warp and bow that standard flat vacuum tables cannot secure
High-speed linear drives with up to 60 m/min rapid traverse maximize throughput on repetitive furniture component families
Extended bed configuration (up to 6,000 mm) enables processing of long architectural elements such as stair stringers and door frames

Limitations

5-axis solid wood machining requires skilled CAM programmers familiar with wood-specific toolpath strategies — steeper learning curve than simple 3-axis panel routing
Premium price versus entry-level 3-axis CNC routers; best justified for shops producing high-complexity shaped components rather than flat panel work
Solid wood variability (grain, knots, moisture) means even well-programmed toolpaths may require operator judgment and occasional intervention that fully automated panels do not

Best For

Bespoke furniture manufacturers producing shaped solid wood components including chairs, cabinets, and decorative elements requiring 5-axis profiling Staircase manufacturers machining curved handrails, complex balusters, and shaped stringers from solid hardwood Window and door manufacturers producing complex sash profiles, glazing rebates, and hardware mortises in solid wood frames Architectural millwork shops fabricating bespoke paneling, cornices, and decorative joinery for high-end residential and commercial interiors

Frequently Asked Questions

01 Can the Record 220 machine solid hardwoods like oak, walnut, and ash?

Yes. The 12 kW spindle and rigid steel gantry handle dense hardwoods including oak, walnut, ash, and maple without deflection issues. Feed rates and depth-of-cut are adjusted in Maestro for hardwood versus softwood, and SCM recommends carbide tooling with appropriate chip geometry for clean cuts in hardwood grain.

02 What is the difference between the Record 220 and a standard 3-axis CNC router?

A 3-axis router can only move in X, Y, and Z — it cannot tilt or rotate the tool. The Record 220's 5-axis head allows the tool to be angled and rotated simultaneously, enabling complex undercuts, shaped profiles, and compound-angle joinery cuts that are impossible on a 3-axis machine without multiple setups.

03 How does the machine handle irregular solid wood blanks that are not flat?

SCM's adjustable vacuum pod system elevates individual pods to contact the underside of warped or bowed boards, providing stable support across the board surface. Lateral clamps prevent movement during heavy cuts. An optional probing cycle measures the actual surface of the blank and adjusts the toolpath Z-depth to match, compensating for thickness variation.

04 Is the Record 220 suitable for processing aluminum or composite panels?

The Record 220 is primarily designed for wood-based materials. While it can route aluminum sheet with appropriate tooling and reduced feed rates, it is not optimized for metal or composite production. For aluminum and composite work, SCM and sister brand CMS offer dedicated metalworking and composite machining centers.

05 What training and support does SCM provide for the Maestro control system?

SCM provides on-site commissioning, operator training, and post-processor setup as part of machine installation. Maestro programming training is available at SCM's training centers in Italy and through regional offices. Online Maestro updates, remote diagnostic support, and an SCM customer portal provide ongoing software and technical assistance.
