Nakamura-Tome JX-200

$450,000 - $700,000 Updated 2026-03-19

Key Specifications

Max Spindle

6,000min-1

Max Turn Length

1,058mm

max turning diameter

325mm / 255mm

left spindle speed

6,000 RPM (4,500 / 3,500 optional)

left spindle power

15/11 kW (20/15 HP) (22/18.5 kW optional)

right spindle speed

6,000 RPM (4,500 / 3,500 optional)

Overview

The Nakamura-Tome JX-200 is an ATC-equipped multitasking machine that combines turning, milling, and drilling operations with automatic tool changing for complex part production in a single setup. The JX-200 features Nakamura-Tome's NT Smart Cube compact tool spindle technology, which enables B-axis swiveling for angled holes and compound-angle milling operations that Y-axis-only machines cannot achieve.

The dual-spindle configuration features a left spindle with 15/11 kW (or optional 22/18.5 kW) and a right spindle with 11/7.5 kW (or optional 15/11 kW), both capable of speeds up to 6,000 RPM (or 4,500/3,500 RPM depending on configuration). Bar capacity of 65 mm (80 mm optional) on the left and 51 mm (65 mm optional) on the right accommodates a range of bar stock sizes. Maximum turning diameter is 325 mm with turning lengths up to 1,058 mm, placing the JX-200 firmly in the medium-size multitasking category.

The 80-tool ATC magazine (40 or 120 optional) provides extensive tool capacity for complex multi-feature parts without mid-program tool loading. Chuck sizes range from 6 to 8 inches with 10-inch optional. The distance between spindles ranges from 240 mm minimum to 1,250 mm maximum, accommodating both compact and long-shaft workpieces.

The machine footprint of 5,250 mm wide by 2,984 mm deep with a height of 2,925 mm reflects the substantial capability packed into the JX-200. This machine competes directly with the Mazak Integrex i-200, DMG Mori NTX 2000, and Okuma Multus B300 as a premium multitasking platform for aerospace, medical, and high-precision contract manufacturing.

Full Specifications

Parameter	Value
Max Turning Diameter	325mm / 255mm
Max Turning Length	1,058mm
Left Spindle Speed	6,000 RPM (4,500 / 3,500 optional)
Left Spindle Power	15/11 kW (20/15 HP) (22/18.5 kW optional)
Right Spindle Speed	6,000 RPM (4,500 / 3,500 optional)
Right Spindle Power	11/7.5 kW (15/10 HP) (15/11 kW optional)
Left Bar Capacity	65 mm (80 mm optional)
Right Bar Capacity	51mm
Chuck Size	6”,8”,(10″*2)
Distance Between Spindles	max.1,250mm / min.240mm
Atc Magazine	80 tools (40 / 120 optional)
B Axis	NT Smart Cube tool spindle
Machine Height	2,925 mm (115.2 in)
Machine Width	5,250 mm (206.7 in)
Machine Depth	2,984 mm (117.5 in)
Max Spindle Speed	6,000min-1
Right Spindle Motor	11/7.5kW
Floor Space	height:2,925mm / width:5,250mm / depth:2,984.4mm

Specifications sourced from nakamura-tome.com — verified 2026-03-28

Strengths & Limitations

Strengths

80-tool ATC magazine eliminates mid-program tool loading on complex multi-feature parts
NT Smart Cube tool spindle with B-axis enables angled holes and compound-angle milling operations
Dual spindles with up to 22/18.5 kW power provide serious cutting capability on both sides
6,000 RPM spindle speeds enable high surface speeds on small diameters and aluminum work
1,058 mm turning length handles long shaft-type aerospace and industrial components
Bar capacity up to 80 mm on the left spindle accommodates a wide range of bar stock sizes

Limitations

$450,000-$700,000 price point is premium and requires complex parts to justify the investment
5,250 mm width requires significant floor space compared to simpler turning centers
Multi-channel programming for simultaneous operations requires advanced CAM software and expertise
Nakamura-Tome dealer network is smaller than Mazak or DMG Mori in most Western markets

Best For

Aerospace manufacturing of complex components with angled holes, contoured pockets, and multi-axis features Medical device production of implants, instruments, and components requiring complete machining in one setup High-precision contract shops bidding complex multi-feature parts that demand multitasking capability Production environments replacing multiple machines with a single multitasking platform for cell consolidation Shops machining complex bar-fed parts up to 80 mm diameter with both-end features and milling operations

Frequently Asked Questions

01 What does a Nakamura-Tome JX-200 cost?

New Nakamura-Tome JX-200 machines price between $450,000 and $700,000 depending on spindle configuration, ATC capacity, and optional equipment. Standard configurations with 80-tool ATC typically fall in the $500,000-$600,000 range.

02 How does the JX-200 compare to the Mazak Integrex i-200?

Both are premium multitasking machines with B-axis milling capability. The JX-200 features Nakamura-Tome's NT Smart Cube technology and up to 120-tool ATC, while the Mazak offers SmoothAi CNC and a larger dealer network. Both deliver similar capability; the choice often comes down to dealer support and operator familiarity.

03 What is the NT Smart Cube technology?

NT Smart Cube is Nakamura-Tome's compact tool spindle design that integrates B-axis swiveling with a milling spindle in a compact package. It enables angled hole drilling, compound-angle milling, and contouring operations that standard Y-axis-only machines cannot perform.

04 How does the JX-200 compare to the smaller NTJ-100?

The JX-200 offers larger turning capacity (325 mm vs 200 mm diameter), longer turning length (1,058 mm vs 550 mm), ATC with up to 120 tools (vs 24 tool stations), and higher spindle power options. The JX-200 is the larger-capacity multitasking platform for medium to large complex parts.
