Mazak Quick Turn 200MY
Key Specifications
X Travel
Y Travel
Z Travel
max turning diameter
max machining length
swing over bed
Overview
The Mazak Quick Turn 200MY is one of the most popular CNC turning centers in North American job shops, combining a proven 8-inch chuck turning platform with Y-axis milling capability and an optional sub spindle for complete part processing. The 'MY' designation means you get both the Milling axis (C-axis with live tooling) and Y-axis off-center capability, turning what would otherwise be a basic 2-axis lathe into a versatile mill-turn workcell.
The main spindle delivers 22 kW (30 hp) at 5,000 RPM through an A2-6 spindle nose with 65 mm (2.56 in) bar capacity. That's a healthy amount of power for an 8-inch chuck machine, handling steel, stainless, and titanium without bogging down on aggressive roughing cuts. The 12-station turret accommodates BMT live tools running at 6,000 RPM with 5.5 kW (7.4 hp), and the Y-axis provides 100 mm (+50/-50 mm) of off-center travel for cross-drilling, milling flats, and machining features that don't fall on the part centerline.
The work envelope covers 300 mm (11.81 in) maximum turning diameter and 500 mm (19.69 in) maximum machining length with axis travels of 200 mm (X) and 550 mm (Z). Rapids hit 30 m/min on both X and Z. An optional sub spindle running 5,000 RPM with 11 kW (15 hp) and a 6-inch chuck handles back-working operations for true done-in-one processing. The tailstock option provides support for longer shaft work.
Current-generation machines run on MAZATROL SmoothEz, Mazak's entry-level conversational CNC that makes the Quick Turn accessible to operators who don't have deep G-code programming experience. Earlier models shipped with Matrix Nexus 2 or SmoothG controls. At roughly 4,500 kg (9,921 lb), the QT-200MY fits comfortably into most shop layouts. New machines typically price between $95,000 and $180,000 depending on configuration, with used units from 2012-2020 trading between $40,000 and $100,000. The Quick Turn 200 competes directly with the Haas ST-20Y, Okuma GENOS L3000-e, and Hardinge Talent 51. Specs sourced from Mazak published data and dealer documentation.
Full Specifications
| Parameter | Value |
|---|---|
| Max Turning Diameter | 300 mm (11.81 in) |
| Max Machining Length | 500 mm (19.69 in) |
| Swing Over Bed | 580 mm (22.83 in) |
| Bar Capacity | 65 mm (2.56 in) |
| X-Axis Travel | 200 mm (7.87 in) |
| Y-Axis Travel | 100 mm (±50 mm) |
| Z-Axis Travel | 550 mm (21.65 in) |
| Main Spindle Speed | 5,000 RPM |
| Main Spindle Power | 22 kW (30 hp) |
| Main Spindle Nose | A2-6 |
| Sub Spindle Speed | 5,000 RPM (optional) |
| Sub Spindle Power | 11 kW (15 hp) (optional) |
| Live Tool Speed | 6,000 RPM |
| Live Tool Power | 5.5 kW (7.4 hp) |
| Tool Stations | 12 (BMT turret) |
| Turret Type | BMT live tooling |
| Chuck Size | 8 in (A2-6) |
| Rapid Traverse X | 30 m/min (1,181 ipm) |
| Rapid Traverse Z | 30 m/min (1,181 ipm) |
| CNC Control | MAZATROL SmoothEz |
| Machine Weight | 4,500 kg (9,921 lb) |
Specifications sourced from mazakusa.com — verified 2026-03-28
Strengths & Limitations
Strengths
- MAZATROL SmoothEz conversational control makes the machine accessible to operators without deep G-code experience, reducing training time and programming errors
- 22 kW main spindle provides excellent power for an 8-inch chuck machine, handling aggressive roughing in steel and stainless without sacrificing surface finish quality
- Y-axis capability with 100 mm travel enables off-center drilling, milling flats, hexagons, and keyways that would otherwise require a second operation on a mill
- Massive installed base across North America means abundant used tooling, experienced operators, proven programs, and fast Mazak service support
- Compact 4,500 kg footprint fits into existing shop layouts and allows multiple QT-200 machines to be lined up for cell-based production
- Optional sub spindle transforms the machine into a complete done-in-one platform for small-to-medium parts requiring back-end machining
Limitations
- 65 mm bar capacity limits the machine to 2.5-inch bar stock; shops regularly running 3-inch or larger bar need the Quick Turn 250 or 350
- 12-station turret fills up quickly when running complex MY programs with multiple live tools; some jobs require creative tooling strategies or multiple runs
- 30 m/min rapids are slower than some competitors like the Haas ST-20Y (30.5 m/min X, 30.5 m/min Z) and Okuma GENOS L3000-e (30 m/min X, 40 m/min Z)
- Live tool power at 5.5 kW is adequate for drilling and light milling but insufficient for heavy face milling or large-diameter boring operations
- MAZATROL SmoothEz is the entry-level control and lacks some advanced features found on the SmoothAi used in higher-end Mazak machines
Best For
Frequently Asked Questions
01
Base QT-200MY configurations with Y-axis and live tooling start around $95,000-$110,000. Adding the sub spindle, high-pressure coolant, chip conveyor, and bar feeder interface pushes the price to $140,000-$180,000. Used QT-200MY machines from 2012-2020 trade between $40,000 and $100,000 depending on hours, control generation, and installed options.
02
The QT-200M has C-axis and live tooling (milling capability) but no Y-axis. The QT-200MY adds Y-axis travel for off-center milling. The QT-200MSY adds both Y-axis and a sub spindle for done-in-one processing. Each step up adds roughly $15,000-$30,000 to the price. Most shops buying new go with the MY or MSY configuration.
03
The Haas ST-20Y is typically $15,000-$25,000 less expensive with comparable specs: 15 kW (20 hp) spindle, 51 mm bar capacity, and similar work envelope. The Mazak counters with a more powerful 22 kW spindle, 65 mm bar capacity, BMT tooling with better runout, and the MAZATROL conversational control. The Haas wins on initial cost and simplicity; the Mazak wins on capability and build quality.
04
The QT-200 has a standard bar feeder interface compatible with LNS, Iemca, FMB, and Edge Technologies bar feeders. The 65 mm bar capacity determines the maximum bar feeder size needed. LNS Quick Load Servo 65 and Iemca Boss 338-HD are popular choices. Budget $15,000-$35,000 for a quality bar feeder depending on length and capacity.
