Hyundai WIA LF2200 II Series
Key Specifications
X Travel
Z Travel
Max Spindle
Rapid Traverse
Spindle Power
Max Turn Length
Overview
The Hyundai WIA LF2200 II Series is a compact front-loading CNC turning center designed for high-speed production of small-diameter chucked parts. The front-loading architecture enables seamless gantry loader and robotic integration for unmanned manufacturing cells. With an 8-inch chuck, 260 mm (10.2 in) maximum turning diameter, and twin turrets carrying 2 x 8 tool stations, the LF2200 II delivers the throughput automotive tier suppliers and precision component manufacturers demand.
The spindle reaches 4,500 RPM with 15/11 kW (20/15 hp) via belt drive, providing excellent surface speed capability on small-to-medium diameter parts. The higher spindle speed compared to the larger LF2600 II reflects the machine's optimization for smaller workpieces where RPM rather than torque drives cycle time. Box way construction on the slide ensures vibration-free cutting and consistent surface finish quality across production runs.
The second-generation II design features an improved Z-axis structure for increased rigidity, and the machine offers a choice between roller LM guide and box guideway configurations. Rapid traverse of 24 m/min (945 ipm) on both axes minimizes idle time between operations. The twin turret system with 2 x 8 stations allows simultaneous OD and ID operations, cutting cycle times by 30-40% versus single-turret turning centers on typical production parts.
The LF2200 II competes with Emag VL 2 and VL 4, Index C100, and similar compact front-loading production lathes. New machines price between $120,000 and $180,000, representing strong value for high-volume production applications. The machine is particularly effective in cells producing bearings, gears, bushings, and small flanged components at automotive production volumes.
Full Specifications
| Parameter | Value |
|---|---|
| Max Turning Diameter | 260 mm (10.2 in) |
| Max Turning Length | mm |
| Chuck Size | inch |
| Max Spindle Speed | 4,500 RPM |
| Spindle Motor Power | 15/11 kW (20/15 hp) |
| Spindle Torque | N.m |
| Turret Stations | 2 x 8 (twin turret) |
| Tool Size | mm |
| Guideway Type | Box ways (LM guide option available) |
| Rapid Traverse Rate | 24/24 m/min (945 ipm) X/Z |
| Spindle Drive | Belt |
| X-Axis Travel | 140 mm (5.5 in) |
| Z-Axis Travel | 170 mm (6.7 in) |
| Loading Type | Front loading |
| CNC Control | Fanuc 0i-TF Plus |
| Description | Unit |
| Max Turning Dia | mm |
| Spindle Rpm | r/min |
| Spindle Output | kW |
| Travel | mm |
| Rapid Travel | m/min |
| No Of Tools | EA |
| Milling Tool Speed | r/min |
| Type Of Business | Business Type 1VehiclesIT/ElectronicsMachinery/ShipbuildingComplex & Precise PartsDie&Mold IndustryEnergyOthersBusiness Type 2 |
| E Mail | @ |
Specifications sourced from wiamachine.com — verified 2026-03-28
Strengths & Limitations
Strengths
- 4,500 RPM spindle speed is well optimized for small-diameter finishing passes where high surface feet per minute drives quality and cycle time
- Twin turret with 2 x 8 tool stations enables simultaneous OD/ID machining, reducing cycle times 30-40% on typical production parts
- Front-loading design integrates directly with gantry loaders and robots for lights-out manufacturing cells
- Box way construction provides excellent vibration damping for consistent surface finishes across production runs
- Improved Z-axis rigidity in the II generation delivers better part quality than the original LF2200 design
- Compact footprint suits high-density production floor layouts where multiple machines share a single gantry loader
Limitations
- 170 mm maximum turning length restricts the machine to very short, disc-shaped parts -- no shaft work capability
- 8-inch chuck and 260 mm turning diameter exclude medium and larger workpieces that require 10-inch or larger chucking
- Front-loading configuration adds cost and complexity that is only justified at production volumes requiring automation
- Hyundai WIA's North American service footprint is less dense than competitors like Haas, Mazak, or DMG MORI
Best For
Frequently Asked Questions
01
New LF2200 II Series machines typically price between $120,000 and $180,000 depending on options and automation configuration. A complete automated cell with gantry loader and part conveyor can reach $200,000-$250,000.
02
The LF2200 II has a smaller 8-inch chuck (vs. 10-inch), 260 mm max turning diameter (vs. 360 mm), and 2 x 8 tool stations (vs. 2 x 10). However, the LF2200 II spins faster at 4,500 RPM (vs. 3,500 RPM), making it better optimized for small-diameter parts.
03
Technically yes, but the front-loading configuration is specifically designed for automated part handling. Manual loading on a front-loading machine is less ergonomic than a standard horizontal lathe. Shops not planning automation would be better served by a standard L-series turning center.
04
The LF2200 II handles all common production turning materials including carbon steel, alloy steel, stainless steel, cast iron, brass, aluminum, and copper alloys. The 15 kW spindle and box way construction provide adequate power and rigidity for production roughing and finishing.
