GF Machining AgieCharmilles FORM X 600
Key Specifications
X/Y/Z Travel
Max Workpiece Dimensions
Max Workpiece Weight
Max Electrode Weight
Surface Finish Ra
Dielectric Capacity
Overview
The GF Machining Solutions AgieCharmilles FORM X 600 is the flagship sinker EDM — the most advanced die-sinking machine the company produces. With X/Y/Z travels of 600 x 400 x 500 mm and a workpiece capacity of 1,200 x 800 x 350 mm rated at 2,000 kg, the FORM X 600 addresses the full spectrum of mid-to-large precision mold and die applications.
The FORM X 600 incorporates the complete FORM X precision package: dielectric oil temperature stabilization to within ±0.5°C, the highest-resolution IPG available in the FORM series, and full ITM active compensation. The IPG achieves Ra 0.08 micron — optical-quality surfaces from the EDM.
The machine structure weighs 5,504 kg, providing mass and rigidity for micron-level positioning. The 900-liter dielectric system maintains stable gap conditions. The AC FORM CNC control supports AEC integration.
The FORM X 600 competes with the Makino EDAC4, Sodick AG60LP, and Mitsubishi EA24V. New machines are priced $250,000-$400,000.
Full Specifications
| Parameter | Value |
|---|---|
| X/Y/Z Travel | 600 x 400 x 500 mm (23.6 x 15.7 x 19.7 in) |
| Max Workpiece Dimensions | 1,200 x 800 x 350 mm (47.2 x 31.5 x 13.8 in) |
| Max Workpiece Weight | 2,000 kg (4,409 lb) |
| Max Electrode Weight | 50 kg (110 lb) |
| Surface Finish Ra | 0.08 µm (2 µin) |
| Dielectric Capacity | 900 L (238 gal) |
| Table-To-Chuck Distance | 200 - 700 mm (7.9 - 27.6 in) |
| Thermal Management | Precision dielectric temperature control (±0.5°C) + full ITM |
| Control System | AC FORM CNC with technology database |
| Power Supply | IPG (Intelligent Power Generator, high-resolution) |
| Auto Electrode Changer | Compatible (AEC option) |
| Machine Dimensions | 1,790 x 2,860 x 3,110 mm (70.5 x 112.6 x 122.1 in) |
| Machine Weight | 5,504 kg (12,134 lb) |
| Machine Dimensions | 1790 x 2860 x 3110 mm70.5 x 112.6 x 122.1 in |
| Machine Weight Without Dielectric | 3830 kg8444 lbs |
| Travel X Y Z | 600 x 400 x 500 mm23.6 x 15.7 x 19.7 in |
| Min Max Distance Between Table And Chuck | 200-700 mm7.87/27.56 in |
| Best Surface Finish Ra | 0.08 μm2 μin |
| Capacity | 900 l237.75 gal |
| Max Workpiece Dimensions | 1200 x 800 x 350 mm47.24 x 31.50 x 13.78 in |
| Max Workpiece Weight | 2000 kg4409.24 lbs |
| Max Electrode Weight | 50 kg110.23 lbs |
| Weight Total Without Dielectric | 5504 kg12134 lbs |
Specifications sourced from gfms.com — verified 2026-03-28
Strengths & Limitations
Strengths
- Ra 0.08 µm finish is the finest in the sinker EDM lineup — optical-quality surfaces
- Precision dielectric temperature control (±0.5°C) with full ITM provides unmatched stability
- 600 x 400 mm X/Y travel with 2,000 kg capacity covers mid-to-large applications
- High-resolution IPG enables seamless roughing to optical-quality finishing
- AEC automation enables fully automated complex cavity production
- 5,504 kg provides structural rigidity for micron-level accuracy
Limitations
- At $250K-$400K, highest-priced mid-size sinker EDM
- Precision temperature control adds infrastructure requirements
- Thermal management complexity increases maintenance
- 50 kg electrode weight is lower than some competitors
