GF AgieCharmilles CUT X

$110,000 - $160,000 Updated 2026-03-14

Key Specifications

X Travel

350 mm (13.8 in)

Y Travel

250 mm (9.8 in)

Z Travel

256 mm (10.1 in)

Accuracy

2 um

u axis

+/-60 mm (+/-2.36 in)

v axis

+/-60 mm (+/-2.36 in)

Overview

The GF AgieCharmilles CUT X bridges the gap between the economy CUT E line and the high-performance CUT S and CUT P series. It shares the compact 350 x 250 x 256 mm (13.8 x 9.8 x 10.1 in) travel envelope with the CUT E 350, but underneath it brings a more capable generator, tighter accuracy, and features that justify the price bump for shops doing precision work.

The upgraded ISPG generator on the CUT X pushes surface finish quality beyond what the CUT E can achieve. Standard machining delivers Ra 0.15 um (6 uin) finish, and with optimized skim passes you can reach below Ra 0.10 um for near-mirror applications. Cutting speed also benefits from the more powerful generator, with roughly 15 percent faster roughing compared to the CUT E on typical tool steel.

Positioning accuracy tightens to 2 um on the CUT X, a meaningful upgrade from the CUT E 3 um specification. For shops cutting precision injection mold components, medical device parts, or tight-tolerance stamping dies, that extra micron of accuracy translates directly to fewer recuts and less hand-fitting at assembly. High-resolution linear glass scales and thermal compensation maintain this accuracy across the full travel range.

The UNIQUA HMI carries over from the CUT E, so operators moving up from the economy line face zero retraining. GF added enhanced process monitoring and parameter optimization features that let experienced operators fine-tune cuts more aggressively. Wire compatibility spans 0.10 to 0.30 mm (0.004 to 0.012 in) as standard, with no optional fine-wire kit needed.

U/V axis travel expands to +/-60 mm (+/-2.36 in) for improved taper cutting capability. Workpiece capacity holds at 500 kg (1,102 lb). The machine weighs approximately 3,500 kg (7,716 lb) without dielectric.

New CUT X machines price between $110,000 and $160,000 depending on configuration. Used machines from 2017-2021 trade in the $55,000-$95,000 range. The CUT X competes with the Sodick ALN400Q, Mitsubishi MV2400R, and Makino U3.

Full Specifications

Parameter	Value
X-Axis Travel	350 mm (13.8 in)
Y-Axis Travel	250 mm (9.8 in)
Z-Axis Travel	256 mm (10.1 in)
U Axis	+/-60 mm (+/-2.36 in)
V Axis	+/-60 mm (+/-2.36 in)
Max Taper Angle	+/-30 deg at 50 mm height
Max Workpiece Size	780 x 550 x 256 mm (30.7 x 21.7 x 10.1 in)
Max Workpiece Weight	500 kg (1,102 lb)
Wire Diameter Range	0.10 - 0.30 mm (0.004 - 0.012 in)
Surface Finish	Ra 0.15 um (6 uin Ra); sub Ra 0.10 um achievable
Positioning Accuracy	2 um
Max Cutting Speed	200 mm2/min (31 in2/hr)
CNC Control	UNIQUA HMI (touchscreen)
Generator	ISPG Advanced
Machine Weight	3,500 kg (7,716 lb) without dielectric
Machine Dimensions	2,350 x 2,100 x 2,280 mm (92.5 x 82.7 x 89.8 in)

Specifications sourced from gfms.com — verified 2026-03-28

Strengths & Limitations

Strengths

2 um positioning accuracy is a significant step up from the CUT E 3 um, enabling tighter-tolerance mold and die work
Fine-wire capability down to 0.10 mm included as standard, no optional kit required like on the CUT E series
Advanced ISPG generator delivers better surface finish consistency and roughly 15 percent faster cutting than the CUT E
UNIQUA HMI carries over from CUT E, meaning zero retraining for operators upgrading from the economy line
Thermal compensation maintains accuracy across the full travel range during long unattended production runs
+/-60 mm U/V axis travel provides more taper capability than the CUT E +/-50 mm for angular work

Limitations

350 mm X-travel is identical to the CUT E 350; shops needing more envelope should consider the CUT P 550 or CUT 1000
Price premium of $30,000-$50,000 over the CUT E 350 is hard to justify for general-purpose work not requiring sub-2 um accuracy
GF Machining Solutions EDM service network in North America is thinner than Makino or Mitsubishi in some regions
500 kg workpiece capacity is adequate but not exceptional for a machine at this price point
No integrated automation system as standard; System 3R integration is available but adds significant cost

Best For

Mold shops stepping up from entry-level wire EDM that need tighter accuracy for precision injection molds Medical device manufacturers cutting tight-tolerance components in exotic materials like titanium and Nitinol Aerospace shops requiring consistent sub-2 um accuracy for turbine components and precision fixturing Tool and die operations doing fine-detail work with 0.10 mm wire as standard equipment Shops transitioning from older Charmilles machines wanting modern controls without operator retraining Production environments requiring thermal stability and accuracy consistency across long unattended cutting cycles

Frequently Asked Questions

01 What does a GF AgieCharmilles CUT X cost?

New CUT X machines typically price between $110,000 and $160,000. Used machines from 2017-2021 trade in the $55,000-$95,000 range.

02 What is the difference between the CUT X and CUT E 350?

Both share 350 x 250 x 256 mm travel, but the CUT X offers 2 um accuracy (vs 3 um), standard fine-wire to 0.10 mm, an advanced ISPG generator, +/-60 mm U/V travel (vs +/-50 mm), and thermal compensation.

03 How does the CUT X compare to the CUT S and CUT P?

The CUT X balances accuracy and versatility at a moderate price. The CUT S prioritizes raw cutting speed. The CUT P delivers the highest accuracy and best surface finish.

04 Can the CUT X handle unattended operation?

Yes. UNIQUA supports job scheduling, automatic wire threading handles breaks, and System 3R automation integration is available.

05 What materials can the CUT X cut?

Any electrically conductive material including tool steel, stainless, carbide, titanium, Inconel, copper, and aluminum.
