DN Solutions LYNX 2100 LSYA

$135,000 - $185,000 Updated 2026-03-19

Key Specifications

Max Spindle

6,000 RPM

Spindle Power

15 kW (20 hp)

Max Turn Length

510 mm

chuck size

6 inch

max turning diameter

300 mm

x axis travel

205 mm (8 in)

Overview

The DN Solutions LYNX 2100 LSYA is a full-featured compact turning center that packs Y-axis milling, live tooling, and a sub-spindle into a 6-inch chuck platform. That designation breaks down as L (long bed), S (sub-spindle), Y (Y-axis), A (6-inch chuck) — making this one of the most capable small-footprint CNC lathes available. If you need to produce complete parts with off-center features from bar stock in a single cycle, this is the machine.

The main spindle delivers 15 kW (20 hp) at 6,000 RPM with 127 Nm (94 ft-lb) of torque through the 6-inch (152 mm) chuck. Max turning diameter is 300 mm (12 in) with 510 mm (20 in) of turning length on the long-bed platform. The 12-station turret runs live tools at 6,000 RPM, and the Y-axis provides ±52.5 mm (±2.07 in) of off-center travel for true milling operations — flats, pockets, slots, and off-center holes that C-axis interpolation alone can't produce efficiently.

The sub-spindle picks up parts after main-spindle operations, enabling complete machining of both ends without operator intervention. Combined with a bar feeder and parts catcher, the LSYA runs lights-out production of finished parts. Axis travels are 205 mm (8 in) on X, ±52.5 mm on Y, and 560 mm (22 in) on Z, with rapid traverse at 30/15/36 m/min on X/Y/Z respectively.

At approximately 4,000 kg (8,818 lb) and a footprint of 2,900 mm (114 in), the LSYA is remarkably compact for a machine with this much capability. Competing Y-axis sub-spindle lathes are typically 20-30% larger. The FANUC 0i-TF Plus control handles the synchronization between main and sub-spindle, Y-axis positioning, and live tool operations with well-established programming methods. Specs sourced from DN Solutions published data.

Full Specifications

Parameter	Value
Chuck Size	6 inch
Max Turning Diameter	300 mm
Max Turning Length	510 mm
X Axis Travel	205 mm (8 in)
Y Axis Travel	±52.5 mm (±2.07 in)
Z Axis Travel	560 mm (22 in)
Rapid Traverse X	30 m/min (1,181 ipm)
Rapid Traverse Y	15 m/min (591 ipm)
Rapid Traverse Z	36 m/min (1,417 ipm)
Max Spindle Speed	6,000 RPM
Spindle Motor Power	15 kW (20 hp)
Spindle Torque	127 Nm (94 ft-lb)
Turret Stations	12-station with live tooling
Rotary Tool Speed	6,000 RPM
Y Axis	Yes
Sub Spindle	Yes
Machine Length	2,900 mm (114 in)
Machine Height	1,693 mm (67 in)
Machine Width	1,650 mm (65 in)
Machine Weight	4,000 kg (8,818 lb)
CNC Control	FANUC 0i-TF Plus
Metric	IMPERIAL
Capacity	Chuck sizeMax. Turning DiameterMax. Turning Length
Travels	X-Axis Rapid TraverseZ-Axis Rapid TraverseX-Axis Travel DistanceY-Axis Travel DistanceZ-Axis Travel Distance
Main Spindle	Max. Spindle SpeedMax. Spindle PowerMax. Spindle Torque
Turret	No. of tool stationRotary Tool r/min
No Of Tool Station	Rotary Tool r/min
Dimensions	LengthHeightWidthWeight
Favorites	Lynx 2600SY
12 Ea	6000 RPM

Specifications sourced from dn-solutions.com — verified 2026-03-28

Strengths & Limitations

Strengths

Y-axis + sub-spindle + live tooling in a compact 6-inch chuck platform — maximum capability per square foot
Y-axis enables true off-center milling: flats, pockets, slots, and off-center holes that C-axis alone can't do efficiently
Sub-spindle enables done-in-one production of complete parts machined on both ends
6,000 RPM main spindle is ideal for high-speed small-part production in aluminum, brass, and steel
Compact 2,900 mm footprint is remarkably small for a Y-axis sub-spindle turning center
Bar feeder + parts catcher compatibility enables true lights-out unattended production

Limitations

15 kW (20 hp) spindle power limits heavy roughing — this is a precision machine, not a hogging machine
6-inch chuck restricts part diameter compared to the LSYB (8-inch) variant
±52.5 mm Y-axis travel limits the size of off-center milled features
Higher purchase price than non-Y and non-sub-spindle LYNX variants — only justified with the right part mix

Best For

Production shops running complex small parts with off-center features machined on both ends Medical device manufacturers making connector bodies, implant components, and fittings with flats and pockets Aerospace shops producing precision fittings, valves, and actuator components from bar stock Automotive manufacturers making fuel system components, sensor housings, and connectors complete in one cycle Contract manufacturers seeking maximum flexibility in a single compact machine for diverse small-part work

Frequently Asked Questions

01 What does the Y-axis add over the LMSA?

The LMSA has live tooling and a sub-spindle but no Y-axis. It can only do on-center and C-axis interpolated milling. The LSYA adds ±52.5 mm of off-center travel, enabling true milling of flats, pockets, hexagons, and off-center features. If your parts have features that aren't centered on the spindle axis, you need the Y.

02 How much more does the LSYA cost over the LMSA?

The Y-axis option typically adds $20,000-$30,000 over the comparable LMSA configuration, putting the LSYA in the $135,000-$185,000 range. It's worth it if you're currently running second-op milling for off-center features.

03 Can the LSYA run unattended?

Yes. With a bar feeder, parts catcher, and chip conveyor, the LSYA produces complete parts across shifts without operator intervention. The sub-spindle handles part transfer, the Y-axis and live tools handle all milling features, and the bar feeder keeps feeding stock.

04 How does the 6-inch LSYA compare to the 8-inch LSYB?

The LSYA (6-inch chuck, 6,000 RPM) is faster for smaller parts. The LSYB (8-inch chuck, 4,500 RPM) handles larger diameters with more torque. Choose the A for parts under 6 inches where speed matters, and the B when you need the extra clamping capacity.
