DN Solutions DNC 65

$200,000 - $300,000 Updated 2026-03-12

Key Specifications

Max Spindle

3,000 RPM

Tool Capacity

ATC with up to 40 tools

Spindle Power

11 kW (15 hp)

chuck size

12inch

max turning diameter

810mm

grinding spindle speed

10,000 RPM

Overview

The DN Solutions DNC 65 is a quartz grinding horizontal turning center purpose-built for machining non-ferrous metals — specifically semiconductor components, quartz parts, and similar materials that demand contamination-free grinding and turning in a single setup. This is not a general-purpose lathe or surface grinder; it's a specialized machine designed to prevent non-ferrous metal penetration into the machine structure while delivering the precision these components require.

The DNC series combines CNC turning capability with an integrated grinding spindle, allowing shops to rough-turn and finish-grind quartz and ceramic components without moving parts between machines. The grinding spindle runs up to 10,000 RPM with a BT40 tool shank, delivering the surface speeds needed for precision grinding of hard, brittle materials. The main turning spindle provides conventional CNC turning capability for rough shaping before the grinding operation refines the final dimensions and surface finish.

The machine runs on a Fanuc control and features an ATC (automatic tool changer) that can hold up to 40 tools, enabling complex multi-operation cycles. The compact footprint keeps floor space requirements reasonable for cleanroom-adjacent installations common in semiconductor manufacturing. DN Solutions designed the DNC series specifically for the semiconductor supply chain, where quartz components like wafer carriers, process tubes, and chamber parts require tight tolerances and pristine surface finishes.

Full Specifications

Parameter	Value
Chuck Size	12inch
Max Turning Diameter	810mm
Max Spindle Speed	3,000 RPM
Spindle Motor Power	11 kW (15 hp)
Grinding Spindle Speed	10,000 RPM
Grinding Spindle Power	7.5 kW (10 hp)
Grinding Spindle Taper	BT40
X Axis Travel	400 mm (15.7 in)
Z Axis Travel	500 mm (19.7 in)
Rapid Traverse X	10 m/min (394 in/min)
Rapid Traverse Z	20 m/min (787 in/min)
Tool Capacity	ATC with up to 40 tools
Machine Weight	3,000 kg (6,614 lb)
CNC Control	Fanuc 0i-Plus
Metric	IMPERIAL

Specifications sourced from dn-solutions.com — verified 2026-03-28

Strengths & Limitations

Strengths

Combined turning and grinding in a single machine eliminates part transfers and re-fixturing for semiconductor quartz components
10,000 RPM grinding spindle with BT40 taper delivers the surface speeds and rigidity needed for precision grinding of brittle materials
Purpose-built design prevents non-ferrous metal contamination — critical for semiconductor component cleanliness requirements
ATC with up to 40 tools enables complex multi-operation cycles without manual intervention
Compact footprint suitable for cleanroom-adjacent installations common in semiconductor fabs

Limitations

Highly specialized machine with limited general-purpose turning capability — not cost-effective for conventional metalcutting work
Niche application limits used market availability and resale value compared to general-purpose CNC lathes
Requires operators trained in both CNC turning and grinding processes for optimal results
Limited dealer network expertise compared to mainstream DN Solutions turning centers

Best For

Semiconductor equipment manufacturers machining quartz process tubes, wafer carriers, and chamber components Optical and photonics companies requiring precision grinding of glass and ceramic parts Shops specializing in non-ferrous metal machining where contamination prevention is critical Contract manufacturers serving the semiconductor supply chain with turn-grind capability

Frequently Asked Questions

01 What does a DN Solutions DNC 65 cost?

New DNC 65 machines run approximately $200,000-$300,000 depending on configuration and tooling package. The specialized nature of these machines means pricing varies significantly by application. Contact DN Solutions or an authorized distributor for exact pricing.

02 What's the difference between the DNC 65 and the DNC 8060?

The DNC 8060 is a larger machine with a 12-inch chuck and 810 mm max turning diameter, compared to the DNC 65's 6.5-inch chuck and 650 mm capacity. The 8060 also features a 2,840 RPM main spindle. Both share the same quartz grinding concept with integrated grinding spindles.

03 Can the DNC 65 machine materials other than quartz?

While designed for quartz and non-ferrous materials used in semiconductor components, the DNC 65 can machine other non-ferrous metals, ceramics, and glass materials. It's not intended for steel or iron machining — use a standard Puma turning center for ferrous metals.

04 What makes the DNC series different from adding a grinding attachment to a standard lathe?

The DNC series is designed from the ground up to prevent non-ferrous metal contamination. Standard lathes with grinding attachments don't have this protection. The DNC's sealed design, contamination barriers, and purpose-built structure ensure the material purity semiconductor components demand.
