AXYZ AF Series CNC Router

$40,000 – $85,000 Updated 2026-03-17

Key Specifications

Working Area (X×Y×Z)

96 × 60 × 6 in (2,438 × 1,524 × 152 mm) standard; 120 × 60 × 6 in 5x10 option

Spindle Power

3 – 7.5 kW water-cooled HSD electrospindle

Max Spindle Speed

24,000 RPM

Feed Rate

Up to 1,500 in/min (38 m/min) rapid

Positioning Accuracy

±0.006 in (±0.152 mm)

Control System

AXYZ Windows-based controller (G-code compatible)

Overview

The AXYZ AF Series is an entry-to-mid-level production CNC router from AXYZ International designed for sign shops, cabinet manufacturers, and light composite fabricators seeking a reliable, well-supported machine at an accessible price point. The AF Series features a fixed gantry (rather than moving-gantry) design on select configurations, combined with a moving table or standard moving-gantry layout depending on the variant, targeting users who prioritize simplicity, low maintenance, and fast setup over maximum throughput or heavy-duty cutting.

Available in 4x8 and 5x10 foot table formats, the AF Series uses AXYZ's standard servo-driven rack-and-pinion motion system and the AXYZ Windows-based controller with full G-code compatibility. The machine ships standard with a water-cooled HSD electrospindle ranging from 3 kW to 7.5 kW, suited to wood, MDF, plastics, and light composites. An optional automatic tool changer is available for shops requiring multi-step production runs.

The AF Series is frequently selected by sign shops transitioning from manual routing or entry-level hobbyist machines to a production-capable platform that can grow with the business. The machine's lower spindle power and lighter frame construction make it less suited to aggressive aluminum or dense composite routing, but for its intended applications in wood, plastics, and sign media, it delivers reliable cut quality and consistent repeatability.

AXYZ supports the AF Series through its North American dealer network, with factory-trained service technicians and replacement parts availability. The AF Series provides a lower-risk entry point into AXYZ's router platform for shops that may later step up to the 6010 or 7200 Series as production demands grow.

Full Specifications

Parameter	Value
Working Area (X×Y×Z)	96 × 60 × 6 in (2,438 × 1,524 × 152 mm) standard; 120 × 60 × 6 in 5x10 option
Spindle Power	3 – 7.5 kW water-cooled HSD electrospindle
Max Spindle Speed	24,000 RPM
Feed Rate	Up to 1,500 in/min (38 m/min) rapid
Positioning Accuracy	±0.006 in (±0.152 mm)
Control System	AXYZ Windows-based controller (G-code compatible)
Table Type	Multi-zone vacuum hold-down
Machine Weight	Approx. 2,500 – 3,200 kg

Strengths & Limitations

Strengths

Accessible entry price for shops transitioning from manual routing to production CNC
Water-cooled HSD electrospindle runs quietly and maintains consistent temperature during extended production runs
Full G-code compatibility with any CAM software with no proprietary post-processor requirement
AXYZ's North American dealer network provides service support comparable to higher-end models
Straightforward machine design simplifies operator training and routine maintenance

Limitations

3–7.5 kW spindle range limits cutting performance in aluminum and dense composites compared to higher-power models
Lighter frame construction results in more vibration at high feed rates versus heavier 6010 or 7200 platforms
6-inch Z-axis travel is restrictive for routing thick foam, dimensional signage, or 3D carving applications

Best For

Sign shops cutting PVC, acrylic, aluminum composite material, and foam board in standard 4x8 and 5x10 formats Cabinet and furniture manufacturers running nested-based production from plywood and MDF sheet Prototype shops and small-volume fabricators needing a reliable production router without heavy-duty capacity Light plastics fabricators cutting HDPE, ABS, and polycarbonate sheet for industrial components

Frequently Asked Questions

01 How does the AXYZ AF Series compare to the 6010?

The AF Series is lighter and less expensive than the 6010, with a lower spindle power range (3–7.5 kW vs. 7.5 kW standard on the 6010) and a lighter frame. For sign, wood, and light plastics work, the AF Series is capable and well-priced. For aluminum routing, composite cutting, or high-production environments with extended duty cycles, the 6010's heavier construction and higher spindle power provide a meaningful advantage.

02 Can the AF Series be upgraded with an automatic tool changer?

Yes. AXYZ offers automatic tool changer options for the AF Series, allowing multi-step programs with different tool diameters and geometries to run without operator intervention. The ATC is typically an 8 or 12-position carousel depending on the spindle configuration.

03 What CAM software is compatible with the AF Series?

The AF Series controller accepts standard G-code, making it compatible with Vectric Aspire, Vectric VCarve, Alphacam, Cabinet Vision, Mastercam, and any other CAM package with a G-code post-processor. AXYZ provides post-processor files for common CAM platforms.
