Amada HRB 2204

$180,000 - $280,000 Updated 2026-03-19

Key Specifications

Press Capacity

2,200 kN / 220 metric tons (247 US tons)

Bending Length

4,300 mm (169.3 in)

Stroke

250 mm (9.8 in)

Open Height

500 mm (19.7 in)

Throat Depth

400 mm (15.7 in)

Approach Speed

200 mm/s (7.9 in/s)

Overview

The Amada HRB 2204 is the largest and most powerful model in Amada's HRB hybrid servo-hydraulic press brake series, delivering 220 metric tons of pressing force across a 4,300 mm bending length. This combination of heavy tonnage and long bed positions the HRB 2204 for fabricators who regularly bend thick plate and wide panels that exceed the capacity of 100-130 ton machines, but who don't need the premium precision and ATC automation of the flagship HG-2204.

The hybrid servo-hydraulic drive system provides the same on-demand hydraulic operation as the smaller HRB models — servo motors control hydraulic flow, generating pressure only during the actual bending stroke. This reduces energy consumption by up to 30% compared to conventional hydraulic press brakes and generates less heat, extending oil life and maintenance intervals. At 220 tons, the energy savings are substantial in absolute terms, as high-tonnage machines consume significant power during continuous-pump operation.

The AMNC 3i CNC control with a 15.6-inch touchscreen manages the programming complexity that comes with a 4.3-meter bed, including automatic bend sequencing, collision checking, and integration with Amada's VPSS 3i offline programming software. The 6-axis backgauge system handles complex part positioning across the long bed. CNC automatic crowning is essential at this bed length, compensating for deflection that would otherwise produce inconsistent angles between the center and ends of the bending length.

The HRB 2204 is manufactured at Amada's North Carolina facility and serves as the heavy-duty workhorse for fabrication shops that need 220-ton capacity at a competitive price point. Compared to the premium HG-2204, the HRB 2204 trades the ±0.001 mm repeatability, ATC option, and 8-axis backgauge for a significantly lower purchase price while retaining the same fundamental hybrid drive efficiency.

Full Specifications

Parameter	Value
Press Capacity	2,200 kN / 220 metric tons (247 US tons)
Bending Length	4,300 mm (169.3 in)
Stroke	250 mm (9.8 in)
Open Height	500 mm (19.7 in)
Throat Depth	400 mm (15.7 in)
Approach Speed	200 mm/s (7.9 in/s)
Pressing Speed	10-20 mm/s (0.4-0.8 in/s)
Return Speed	200 mm/s (7.9 in/s)
Ram Repeatability	±0.01 mm (±0.0004 in)
Drive System	Hybrid servo-hydraulic
Control	Amada AMNC 3i (15.6-inch touchscreen)
Backgauge Axes	6-axis
Crowning	CNC automatic crowning
Energy Savings	Up to 30% vs conventional hydraulic
Machine Weight	Approximately 18,000 kg (39,683 lb)

Specifications sourced from amada.com — verified 2026-03-28

Strengths & Limitations

Strengths

220 tons across 4,300 mm handles heavy plate bending on wide panels that exceed the capacity of 100-130 ton machines
Hybrid servo-hydraulic drive delivers substantial energy savings at this tonnage where conventional hydraulic pump costs are highest
CNC automatic crowning compensates for deflection across 4.3 meters, maintaining angle consistency from end to end
AMNC 3i control with automatic sequencing manages the programming complexity of long-bed, heavy-tonnage bending
Made in USA at Amada's North Carolina facility with established domestic service infrastructure
Significantly lower price than the premium HG-2204 while sharing the same hybrid servo-hydraulic drive architecture

Limitations

±0.01 mm ram repeatability is adequate for most heavy fabrication but less precise than the HG-2204's ±0.001 mm
No Automatic Tool Changer option — high-mix shops needing ATC at this tonnage must upgrade to the HG-2204
18,000 kg machine weight requires proper foundation preparation and overhead crane access for installation
4.3-meter machine requires significant floor space and material handling equipment for heavy sheet and plate

Best For

Heavy fabrication shops bending thick mild steel plate (8-12 mm) and stainless (6-8 mm) on 4-meter sheets Structural steel, construction equipment, and industrial machinery fabricators needing 220-ton capacity Shops that need heavy-duty Amada bending capability without the HG-2204's premium pricing Fleet standardization where HRB series machines are already in operation at smaller tonnages Regional heavy fabrication shops serving as the area source for large-format, high-tonnage bending

Frequently Asked Questions

01 HRB 2204 vs HG-2204 — what is the difference?

Both deliver 220 tons across 4.3 meters with hybrid servo-hydraulic drive. The HG-2204 offers ±0.001 mm repeatability (vs ±0.01 mm), optional ATC automatic tool changer with 34 meters of tooling storage, 8-axis backgauge with L-shift, sheet followers, and a 19-inch display. The HRB 2204 is the value option at roughly 50-60% of the HG-2204 price, serving shops that need the tonnage without ATC automation.

02 What mild steel thickness can the HRB 2204 bend at full length?

With 220 metric tons across 4,300 mm, the HRB 2204 air-bends mild steel up to approximately 12 mm at full bed length depending on die width and V-opening. On shorter bends using less of the bed, proportionally thicker material — up to 16 mm or more — can be bent within the tonnage capacity.

03 What foundation does the HRB 2204 require?

At approximately 18,000 kg, the HRB 2204 requires a reinforced concrete foundation designed for the static and dynamic loads of the machine. Amada provides foundation drawings as part of the installation documentation. Overhead crane access of at least 10 tons is recommended for tooling handling and maintenance.

04 Can the HRB 2204 handle structural steel bending?

Yes. At 220 tons, the HRB 2204 handles structural steel bending including heavy plate, angle iron, channel sections, and flat bar. The 4.3-meter bed accommodates long structural members. For very heavy structural work, the HG-8025 with 250 tons across 8 meters should be considered.
